Peavey
Scorpion
®
speakers
feature convenient
eld-replaceable
baskets. Replaceable
baskets eliminate the
need for re-coning
speakers and the
frustration and delays
associated with the
re-coning process. It
only takes a few minutes
to replace a basket
and you are back in
business. It just can’t get
any easier than the four
steps outlined here.
1 Remove three screws on back of magnet structure.
2 Lift the magnet structure off the basket frame.
3 Clean the voice coil “gap”.
4 Align screw holes, lower structure into place on new
basket frame, insert screws and tighten.
Baskets are replaced in four easy steps:
ONE YEAR LIMITED WARRANTY
NOTE: For details, refer to the warranty statement. Copies of this statement may be obtained online at www.peavey.com.
1
2
3
4
