Faders
These
are
the
master
faders
for
all
channels
and
determine
the
overall
main,
or
ā€œHouse,"
mix
levels.
They
may
also
be
used
to
set
2
track
recording
levels
for
studio
applications.
HEADPHONE
Fader
(17)
Adjusts
selected
signal
levels
to
the
headphone
jack.
When
the
SOLO
facility
is
inactive,
pre
fader
signals
are
taken
from
the
Left
and
Right
main
faders
and
routed
to
the
headphone
jack.
When
the
SOLO
facility
is
active,
the
selected
soloed
signals
are
routed
to
the
headphone
jack.
Use
only
stereo
headphones
of
8-300
ohms
im¬
pedance.
High-quality
stereo
headphones
are
ideal
for
this
application.
HEADPHONE
Jack
(18)
This
stereo
jack
allows
signal
to
How
to
both
sides
of
any
stereo
headset.
Tip
=
Left,
Ring
=
Right.
SOLO
LED
(19)
This
LED
lights
whenever
the
SOLO
facility
is
active.
NOTE:
The
SOLO
facility
is
active
whenever
any
solo
switch
is
in
the
down
position.
When
the
SOLO
facility
is
active,
the
SOLO
LED
(19)
illuminates,
the
solo
signal
replaces
the
normal
L&R
signals
in
the
headphone
jack
(IS)
and
the
Meters
(38)
show
the
level
of
the
soloed
signal.
L/R
MUTE
Push
Button
Switch
(20)
Mutes
the
LEFT
and
RIGHT
MAIN
OUTPUT
jacks
(46)
when
this
switch
is
placed
in
the
down
position.
ALT
SOLO
Push
Button
Switch
(21)
Routes
ALT
L
and
ALT
R
Output
(47)
signals
to
the
headphone
jack
(18)
when
the
ALT
SOLO
(21)
switch
is
in
the
down
position.
SOLO
TO
MAIN
Push
Button
Switch
(22)
Routes
all
solo
selected
channels
to
the
L
&
R
outputs
when
the
SOLO
TO
MAIN
switch
(22)
is
in
the
down
position.
The
solo
signal
replaces
the
signal
normally
heard
in
the
L&R
outputs.
RETURN
SOLO
Push
Button
Switch
(23)
Routes
all
returns
to
the
SOLO
mix
when
the
RETURN
SOLO
(23)
switch
is
in
the
down
position.
RETURN
4
SECTION:
MONITOR
Control
(24)
Adjusts
the
level
of
the
return
signal
sent
to
the
monitor
mix.
Counter¬
clockwise
rotation
decreases
monitor
gain.
Clockwise
rotation
increases
monitor
gain.
Level
Control
(25)
Adjusts
the
level
of
the
return
4
signal
sent
to
the
L&R
mixes.
This
is
a
stereo
signal.
Counter-clockwise
rotation
decreases
Return
4
gain.
Clockwise
rotation
increases
Return
4
gain.
