Peavey XR 1000L

25
Specifications
Features and specifications subject to change without notice.
Peavey Electronics Corporation • 5022 Hartley Peavey Drive • Meridian, MS • 39305
(601) 483-5365 • FAX (601) 486-1278 • www.peavey.com • EX000139 • ©2011
INPUT SENSITIVITY:
Mic In to full power at the power amp. Master Volume Nom.
Full Nominal
-45 dBu -2
5 dBu
Line In to full power at the power amp. Master Volume Nom.
Full Nominal
-1
5 dBu
+
5 dBu
CHANNEL EQ:
Shelving EQ
Low EQ 80 Hz ±15 dB
Mid-Morph
Low 250 Hz ±15 dB
High 4 kHz ±15 dB
High EQ 12 kHz ±15 dB
CLIP LED:
Clip LEDs come on 3 dB before clipping.
FREQUENCY RESPONSE:
All controls nominal (detent)
Mic to Main 20 Hz – 20 kHz +0, -1 dB
Line to Main 20 Hz – 30 kHz +0, -1 dB
Mic to Amp 50 Hz – 20 kHz +0, -3 dB
Line to Amp 40 Hz – 20 kHz +0, -3 dB
PHANTOM POWER:
+15 VOLTS
NOISE:
Main = Main line output, 22 – 22 kHz filter
Amp 1 = Amplifier output, loaded at 4 Ohms, through AP
AUX-0025 switching amplifier filter
All controls full down.
Main <-95 dBu
Amp 1 <-60 dBu
Master Volume nominal
Main <-88 dBu
Amp 1 <-55 dBu
THD:
All controls nominal
<
0.01% @ main line output, -26 dBu in mic input Channel 1
<
0.1% @ amp 1 @ 400 Watts into 4 Ohms
All controls nominal
<
0.005% @ main line output, +4.5 dBu in line input Channel
1 <0.1% @ amp 1 @ 400 Watts into 4 Ohms
MASTER EQ:
80Hz ±12 dB
250Hz ±12 dB
500Hz ±12 dB
1kHz ±12 dB
2kHz ±12 dB
4kHz ±12 dB
10kHz ±12 dB
METER ARRAY:
LIMIT
-6 dB
-12 dB
-18 dB
-24 dB
-30 dB
AMP LIMITER:
Limits amplifier power just before clipping. The limiter holds the amp power
without clipping and can be driven up to 18 dB past maximum output.
AMPLIFIER OUTPUT POWER:
120VAC
B
oth channels loaded at 8 ohms: 300 Watts RMS per ch
Both channels loaded at 4 ohms: 500 Watts RMS per ch
POWER REQUIREMENTS:
Domestic: 120VAC 50/60Hz
Export: 230VAC 50/60Hz
350 Watts Nominal
350 Watts Nominal
SIZE:
Dimensions: H x W x D
11.25” x 19.375” x 10.75”
WEIGHT: 35.8 lbs.
