Peavey XR 800F User Manual

XR 800F
Specifications:
Input Specifications:
Function Input Z Input Gains Input Levels Bal/ Connector
(ohms) Min** Nominal* Max UnBal.
Min
Low-Z Mic 2.2 k Max (48 dB) -68 dBu -48 dBu -27 dBu Bal. XLR: Pin 1 Gnd,
(150 ohms) Min (10 dB) Pin 2 (+),
Pin 3 (-)
-30 dBu -10 dBu +11 dBu
Line Input 22 k Max -49 dBu -29 dBu -8 dBu Unbal. 1/4" TRS: Tip (+),
Channels 1-6 (29 dB) Ring (-),
Sleeve Ground
Min -11 dBu +10 dBu +31 dBu
(-10 dB)
Stereo Line 22 k Max Gain -20 dBu 0 dBu +21 dBu Unbal. 1/4" Phono Tip (+),
Inputs Chs. 7-8 (20) dB) Sleeve Ground
Tape 20 k Max. Gain -26 dBu -6 dBu +16 dBu Unbal. RCA Jacks
(26 dB)
0 dBVu=0.775 V (RMS)
** Min input level (sensitivity) is the smallest signal that will produce nominal output (2 dBu) with channel and master
level controls set for maximum gain.
* Nominal settings are defined as all controls set a 0 dB (or 50% rotation for rotary pots).
XR 800F Output Specifications:
Function Minimum Load Z Output Level Bal./Unbal. Connector
(ohms)
Nominal Max
Main L/R 600 +2 dBu +21 dbu Unbal. 1/4" Phono Tip (+),
Sleeve Ground
Monitor 600 +2 dBu +21 dBu Unbal. 1/4" Phono Tip (+),
Sleeve Ground
Effects 600 +2 dBu +21 dBu Unbal. 1/4" Phono Tip (+),
Sleeve Ground
Tape 10 k -10 dBu +10 dBu Unbal. RCA
+2 dBu = 0 dBV = 1V (RMS)
Gain:
Mic Input Adjustment Range:
Mic Input to L and R Output
Mic Input longest path
Mic Input Adjustment Range:
Line Input to L and R Output
Mic Input longest path
10 dB to 48 dB
68 dB (Max Gain)
96 dB (Max Gain) power amp out
-10 dB to 28 dB
49 dB (Max Gain)
77 dB (Max Gain) power amp out
