Page #17 background imageLoading...
Page #17 background image
17
Power Section:
1200 SC Module with DDT
Rated Power:
600W program into 4 ohms, both
channels driven / 500W RMS into
4 ohms, both channels driven
475W program into 8 ohms, both
channels driven / 360W RMS into
8 ohms, both channels driven
Frequency Response:
20Hz-20kHz +0dB/-1dB @ rated
power
Total Harmonic Distortion (THD)
<0.01% @ rated output @ 1kHz
DDT Dynamic Range:
Greater than 26dB
DDT Maximum Distortion:
Below 0.5% THD for 6dB overload
Below 1% THD for 20dB overload
Hum and Noise:
97dB below rated power level
(500W)
Damping Factor:
Greater than 100 @ 1kHz, 4 ohms
Input Sensitivity:
1.5 V RMS for 500W @ 4 ohms
Input Impedance:
8.25k ohms
Power Requirements:
DOM: 120VAC 60Hz 500W nominal
EXP: 220-230VAC/240VAC 50/60Hz
500W nominal
Dimensions (WxHxD):
19.0" x 10.75" x 11"
Weight:
41.7 lbs
XR 8600 - Power Amplier Specications
XR
®
8300 & XR
®
8600 Specications
