Pecron E2000 LFP - SOLAR PANEL CONNECTION EXAMPLES; 1200 W (6 x200 W) Connection

USING SOLAR PANELS TO CHARGE THE E2000 LFP
support@pecron.com
Using the pecron 200W /36V*6（1200W）to charge the E2000 LFP
MC4 Solar Charging Cable*2
Y Branch MC4 Charging Cable(+)*2
Y Branch MC4 Charging Cable(-)*2
pecron 200W*6
※ 36V is the operating voltage of the solar panels
36V
36V
36V
36V
36V
36V
36V
36V
