Pecron E2400 LFP - Page 4

E2400
AC OUTPUT-2400W
DC OUTPUT
12V-30A(MAX)
12V-5A 12V-10A
12V-10A
USB
100W 18W 18W
18W 18W 18W
32V~95V
700W(MAX)
12V~18V
100W(MAX)
DC INPUT
100V~120V-15A(MAX)
AC INPUT
HOW TO USE THE E2400 LFP
press and hold to turn on / off DC / USB
press and hold to turn on / off AC
support@pecron.com
(Please turn off the AC function if there is no AC load on the unit)
DC
AC
AC
DC
5521 *1
MJ32 *1 Cascade with max 2 pieces of EP3000-48V
3 5
4
2 1
12V~18V 100W Max 7A Max
DC INPUT
EXTRA BATTERY PORT
AC INLET *1
GX16MF *1
AC INPUT
100Vac - 1500W Max
110Vac - 1650W Max
120Vac - 1800W Max
32V~95V 700W Max 15A Max
