USING SOLAR PANELS TO CHARGE THE E3000
1. 1x DC5521 Charging Port: PV/DC 12V~18V, 100W maximum; VOC(open circuit voltage) of solar panel must be than 25V;
2. 2x GX16MF-5 Charging Port: PV(operating voltage) range 32V~95V, 600W maximum; VOC(open circuit voltage) of
solar panel/array must be than 95V, otherwise, it will damage the unit! Do not wire more than two 36V(AKA 24V)
solar panels in series, or more than four 18V(AKA 12V) solar panels in series.
(18V/36V stands for Vmp, the operating voltage, of the solar panel)
3. If you have any questions, Please feel free to contact us：support@pecron.com
1x DC5521 Charging Port:
PV12V~18V-100W Maximum Input
2x GX16MF-5 Charging Port:
PV32~95V-600W Maximum Input
