Please use the official cascading cable with MJ32 socket when you want to connect
with 4 pcs of expansion battery pack (EP3000-48V) to avoid damage of the power station.
Notes about cascade:
1: Cascading will be faster if there is only 10% difference between the main power station
and the expansion battery pack.
2: Before cascading, please make sure the number of knob on the battery pack is unique.
The number should be adjusted to 0,1,2,3 according to the number of packs.
If the number is wrong, the parameters of the packs
will not be shown on the display of the main power
station.
EXPANDABLE BATTERY
UPS FUNCTION
The E3600 LFP supports UPS function. It can provide the loads(such as computers, data centers, telecommunication
equipment) near-instantaneous(within 8~20ms) protection from unexpected power interruptions of the main power
supply.
Note: Not applicable to specific applications that need transfer time under 8ms, such as servers and workstations.
This UPS function only support protection for loads under 3600W(120V), we recommend that you only
connect one device at a time to avoid overload and thus result in protection failure.
PECRON is not responsible for any devices damage or loss of data resulting from failing to follow the instructions.
DC INPUT
32V~150V
1200W(MAX)*2
12V~30V
150W(MAX)
AC OUTPUT - 3600W
18W
18W
USB
12V
12V-10A12V-5A
12V-30A
DC OUTPUT
DC
E3600
AC
100W 18W
18W 18W
AC INPUT
Overcurrent Protection
Synchronous
interface
100Vac~120Vac 30A MAX
L N
3
1 2
EP3000-48V 3072Wh
EP3000-48V 3072Wh
3 5
4
2 1
3 5
4
2 1
25%
EXTRA BATTERY PORT 1 EXTRA BATTERY PORT 2
50% 75% 100%
EP3000-48V
