16

11.0 MUFFLER FILTER FOR SUCTION, PG-30

ABSORBING

SOUNDPROOFING

MUFFLER CARTRIDGE

EXTERNAL

CARTRIDGE OPENING

EXTERNAL MUFFLER

INTERNAL MUFFLER

CARTRIDGE

CARTRIDGE

FILTER

FILTER CARTRIDGE

SUPPORT

ENSURE CORRECT ALIGNMENT OF

MUFFLER CARTRIDGE OPENINGS

WITH THE OPENING OF SUCTION FILTER

CARTRIDGE OPENING

INTERIOR MUFFLER

SUCTION

OPENING

PRESSURE FILTER
