PEELLE 2745 - Technical Specifications

Model 2745, Wireless Door Controller Installation and Operation Manual
The Peelle Company Guide 224
www.peelledoor.com Page 5 April 2011
III. TECHNICAL SPECIFICATIONS
Technical data Specification
Input Power
5.5 A @ 240 V, 1500 W
Supply Voltage
208-240 Vac, 50-60 Hz, 1~ (L, N, PE)
Output to Motor
0-220 V AC, 0…60 Hz (variable), 3~ (U, V, W)
Output Power
0.75 kW (1 HP), 4.2 A Max
Digital Inputs
7 provided, 12-30 V AC or DC
Encoder Input
Incremental, NPN, 24 VDC, 400 PPR
Relay Outputs
8 provided, Form C, 125 Vac, 10 A Max
Input/Output Indicators
LED
Enclosure Protection
IP 20 (IP 65 optional)
Temperature Range
-10 to 40 deg. C
Dimensions
200 mm x 430 mm x 85 mm (W x H x D)
Mounting Method
4 screw holes on outside perimeter
Wireless Network
IEEE 802.15.4
Wireless Network Range
100 m
User Interface
Onboard pushbuttons with visual display
Visual Display
2” x 1.5” LCD (4 COM x 32 Segments)
Parameters
Max. 100 user adjustable with factory presets
Learn Adjustment
Automatic with user parameter
Door Address
User selectable parameter
Car or Hall Door Type
User selectable parameter
Fail Safe Condition
Door stop if communication lost
Standards
ASME-A17.1/CSA-B44
ASME-A17.5/CSA-B44.1
EN 81
EN 12016
Markings
ETL Mark by Intertek Testing Services
