C. ACCESSIBILITY CLEARANCES
1. The PUREFIRE
®
boiler is certified for closet installations
with zero clearance to combustible construction. In
addition, it is design certified for use on combustible
floors. Do not install on carpeting.
2. Figure 1.1 shows the minimum recommended
clearances to allow reasonable access to the boiler
for Models PF-50, PF-80, PF-110 and PF-140.
For Models PF-200, PF-210, PF-300 and PF-399,
Figure 1.2 shows the minimum recommended
accessibility clearances. However, Local codes or
special conditions may require greater clearances.
PREINSTALLATION
Figure 1.1: Minimum Accessibility Clearances – PF-50, PF-80, PF-110 & PF-140
Figure 1.2: Minimum Accessibility Clearances – PF-200, PF-210, PF-300 & PF-399
3
DANGER
DO NOT INSTALL ON CARPETING.
