REPAIR PARTS
Table 13.2: Heat Exchanger/Burner Assembly Repair Parts – PF-50, PF-80, PF-110 & PF-140
Description
Quantity
Required
Stock
Code
1 Kit Igniter & Cable w / Gasket & Hardware 1 54246
1a Igniter Only 1 54224
1b Igniter Cable 1 54298
1c Igniter Gasket 1 54123
2 Flame Sensor w / Gasket & Hardware 1 54247
2a Flame Sensor only 1 54295
2b Flame Sensor Gasket 1 54124
3 Screw, M4 x 8mm 4 6507
4 Screw, M5.5 x 14mm 5 6506
5 Channel, Air Inlet 1 54182
6 Gasket, Channel to Burner 1 54186
7
Burner – PF-50 1 54174
Burner – PF-80 1 54175
Burner – PF-110 1 54176
Burner – PF-140 1 54177
8 Nut, M6, 10MM Hex 6 51614
9 Combustion Chamber Cover Rate, includes items #45-#47, obs 1 54183
10 Gasket, Rubber 1 54187
11 Insulation, Combustion Chamber Cover Plate 1 54255
12 M4 X 16 MM SS Screw Target Wall 1 6511
13 Washer, M4 1 6510
14 Insulation, Target Wall 1 54185
15
Heat Exchanger – PF-50/80 1 5411
Heat Exchanger – PF-110 1 5412
Heat Exchanger – PF-140 1 5413
16 Gasket, Blower to Channel 1 54122
17
Blower – PF-50/80 1 54189
Blower – PF-110 1 54190
Blower – PF-140 1 54191
18 M5 X 12MM Screw 4 5415
19 Blower Adapter Rate 1 5421
20 M4 x 10mm Screw 3 5422
21
Swirl Plate – PF-50/80, Black 1 54143
Swirl Plate – PF-110, White 1 54145
Swirl Plate – PF-140, Red 1 54146
22
Gas Valve – PF-50180, w / Mtg. Flange, Swirl Rate & Screws 1 54179
Gas Valve – PF-110, w / Mtg. Flange, Swirl Rate & Screws 1 54180
Gas Valve – PF-140, w / Mtg. Flange, Swirl Rate & Screws 1 54181
23 Rectifier Cap Screw, M4 x 30mm, (Local Hardware Supply) 1 54125
24
PF-50/80/110 – Screw, M4 x 20mm 4 5518
PF-140 – Screw, M4 x 25mm 4 5519
Vent Terminations
– 3" Stainless Steel Screen 1 54196
– 4" Stainless Steel Screen 1 54213
– 3" PVC Tee 1 54151
– 4" PVC Tee 1 54218
– 3" PVC Coupling 1 54152
– 4" PVC Coupling 1 54219
