REPAIR PARTS
Table 13.3: General Repair Parts – PF-200, PF-210, PF-300 & PF-399
Description
Quantity
Required
Stock
Code
1 Panel, Jacket Front Door, with Ball Studs 1 54256
2 Lens for Jacket Front Door 1 54167
3 Display Module 852RC (PF-50/399) 1 54702
4 Gasket for Display Bracket 1 54513
5 Bracket for Display Module 1 PF2007-1
6 Hex Nut, #6-32 with Lock washer (Local Hdwr Supply) 2 51553
7 Screw, #6-32 x 1/2" LG Phillips Head, (Local Hdwr Supply) 2 5449
8
Flexible Gas Line – 3/4" – PF-200/210 1 54497
Flexible Gas Line – 3/4" – PF-300/399 1 54262
9 Manual Shut-off Valve, 3/4" NPT, Full Port 1 51805
10 Screw, #10 x 1/2" LG Hex. Hd., (Local Hdwr Supply) 4 99992
11 Jacket, Lower Front Panel 1 PF6051
12 Bulk Head Fitting for Condensate Hose 1 54140
13 Gasket for Bulk Head Fitting 1 54134
14 Leg Leveler 4 5429
15
Coupling, 1" NPT Brass, (Local Hdwr Supply) – PF-210 2 5534
Coupling, 1-1/2" NPT Brass, (Local Hdwr Supply) – PF-399 2 5551
16
Nipple, 1" NPT x 14" LG Brass, (Local Hdwr Supply) – PF-210 2 5557
Nipple, 1-1/2" NPT x 14" LG Brass, (Local Hdwr Supply) – PF-399 2 5550
17
Elbow, 1" NPT Brass, (Local Hdwr Supply) – PF-210 1 5558
Elbow, 1-1/2" NPT Brass, (Local Hdwr Supply) – PF-399 1 5553
18
Tee, 1" NPT Brass, (Local Hdwr Supply) – PF-210 1 5537
Tee, 1-1/2" NPT Brass, (Local Hdwr Supply) – PF-399 1 5554
19
Nipple, 1" NPT x 3" Brass, (Local Hdwr Supply) – PF-210 2 5559
Nipple, 1-1/2" NPT x 3" Brass, (Local Hdwr Supply) – PF-399 2 5552
20
Bushing, 1" x 3/4" NPT Brass, (Local Hdwr Supply) – PF-200/210 1 5539
Bushing, 1-1/2" x 3/4" NPT Brass, (Local Hdwr Supply) – PF-300/399 1 5556
21 Shut-off Valve, 3/4" NPT Brass, (Local Hdwr Supply) 1 50764
22 Convenience Outlet 1 54136
23 Hex. Nut, #8-32 with Lockwasher, (Local Hdwr Supply) 4 51573
24
Control Module, 852MN – PF-200 1 54685
Control Module, 852MN – PF-210 1 54287
Control Module, 852MN – PF-300 1 54683
Control Module, 852MN – PF-399 1 54287
25 3.15A. 250V 5x20mm Slow-Blow Glass Fuse, Radio Shack-270-1067 1 5650
26 Rocker Switch (20A, 120 VAC, (Local Hdwr Supply) 1 6050
27 Pump Isolation Relay Module Kit Includes harness 1 54610
28 10-Amp 125V 5x20mm Slow Blow Fuse, Radio Shack-270-152 4 —
29
Vent/Air Inlet Adapter - PF-200/210 1 54293
Vent/Air Inlet Adapter - PF-300/399 1 54294
30
Vent Adapter Gasket - PF-200/210 1 54133
Vent Adapter Gasket - PF-300/399 1 54217
31 Screw #10 x 3/4" Long Phillips Pan Head 6 5611
32
Heat Exchanger Outlet Collar 3" PF-200/210 1 5531
Heat Exchanger Outlet Collar 4" PF-300/399 1 5532
33 Condensate Neutralizer Assembly 1 54204
34 Condensate Receiver Assembly 1 54259
35 Blocked Vent Switch Kit - Include Items #36 & #37 1 54260
36 1/4" ID PVC Tubing x 12" Long 1 5697
37 90° Barbed Elbow - Polypropylene Adapter Fitting 1 5698
38 Gasket - Cover Plate 1 54141
39 Cover Plate for Thermal Temperature Switch 1 PF2021
40 High Temperature Limit Switch - Tasseron TSDS950 - 95C 1 54419
41 Supply/Return Sensor - 12 KΩ Tasseron TSD00BS 1 54418
42 Flue Sensor Grommet - EPDM 1 54291
43 Flue Sensor - 12 KΩ Tasseron TSD20B0 1 54209
44 Thermal Temp Limit Switch - 605 F 1 54475
– Wiring Harness, Power (Right Terminal Block) 1 PF7022
– Wiring Harness, Control (Left Terminal Block) 1 PF7021
– Wiring Harness, Gas Valve & Flame Sensor 1 PF7023
– Wiring Harness, Ground Wire 1 PF7024
– Push-on Terminal Block (Field Wiring) 10-pole 2 5450
– Push-on Terminal Block (Field Wiring) 6-pole 2 5547
– Relief Valve 1 50664
– Outdoor Sensor, 12kOhm Tasseron TSA00B4 1 54112
