REPAIR PARTS
Table 13.4: Heat Exchanger/Burner Assembly Repair Parts – PF-200, PF-210, PF-300 & PF-399
Description
Quantity
Required
Stock
Code
1 Kit Igniter & Cable w/ Hardware, PF50/80/110/140 1 54246
1a Igniter Only 1 54224
1b Igniter Cable 1 54298
1c Igniter Gasket 1 54123
2 Flame Sensor, with Gasket, Rauschert 1 54247
2a Flame Sensor Only 1 54295
2b Flame Sensor Gasket 1 54124
3 Screw, M4 X 8mm, (Local Hdwr Supply) 4 6507
4 Screw, M5.5 x 14mm 5 6506
5
Premix Channel – PF-200/210 1 54249
Premix Channel – PF-300/399 1 54250
6 Gasket, Channel to Burner 1 54186
7
Burner – PF-200/210 1 54263
Burner – PF-300/399 1 54264
8 Nut, M6, 10MM Hex, (Local Hdwr Supply) 6 61614
9
210 Combustion Chamber Cover Plate Kit, Current, Current, includes items #8-#12 1 54206
399 Combustion Chamber Cover Plate Kit, Current, Current, includes items #8-#12 1 54207
9a Combustion Chamber Cover PF 1 54183
10 Thermal Temp Limit - Manual Reset, 435F – Burner Plate 1 50045
11 Gasket, Rubber 1 54187
12 Insulation, Combustion Chamber Cover Plate 1 54255
13 M4 X 8 MM SS Screw Target Wall, (Local Hdwr Supply) 1 6511
14 Washer, M4, (Local Hdwr Supply) 1 6510
15 Insulation, Target Wall 1 54185
16
Heat Exchanger – PF-200/210 1 5529
Heat Exchanger – PF-300/399 1 5530
17 Gasket, Blower to Channel 1 54122
18
Blower Kit, PF-200/210 1 54258
Blower Kit, PF-300/399 1 54257
19 M5 X 12MM Screw, (Local Hdwr Supply) 4 5415
20
Blower Adapter Plate – PF-200/210 - ø43 mm 1 5421
Blower Adapter Plate – PF-300/399 - ø50 mm 1 5610
21 M4 x 10mm Screw - Phillips Flat Head 3 5422
22
Swirl Plate – PF-210, Grey 1 54251
Swirl Plate – PF-399, Black 1 54252
23
Gas Valve – PF-210, includes item #22 1 54253
Gas Valve – PF-399, includes item #22 1 54254
24
PF-210, Screw M4 x 25 mm T20 TORX 3 5519
PF-399, Screw M4 x 30 mm T20 TORX 3 5621
