REPAIR PARTS
Table 13.2: Heat Exchanger/Burner Assembly Repair Parts – PF-50, PF-80, PF-110 & PF-140
Description
Quantity
Required
Stock
Code
42
Burner – PF-50 1 54174
Burner – PF-80 1 54175
Burner – PF-110 1 54176
Burner – PF-140 1 54177
44 Combustion Chamber Cover Plate, includes items #45-#47 1 54183
45 Gasket, Glass Rope 1 54188
46 Gasket, Rubber 1 54187
47 Insulation, Combustion Chamber Cover Plate 1 54184
50 Insulation, Target Wall 1 54185
51
Heat Exchanger – PF-50 1 5410
Heat Exchanger – PF-80 1 5411
Heat Exchanger – PF-110 1 5412
Heat Exchanger – PF-140 1 5413
52 Gasket, Blower to Channel 1 54122
53
Blower – PF-50, PF-80 1 54189
Blower – PF-110 1 54190
Blower – PF-140 1 54191
55 Blower Adapter Plate 1 5421
57
Swirl Plate – PF-50, Blue 1 54144
Swirl Plate – PF-80, Black 1 54143
Swirl Plate – PF-110, White 1 54145
Swirl Plate – PF-140, Red 1 54146
58
Gas Valve – PF-50, w/ Mtg. Flange, Swirl Plate & Screws 1 54178
Gas Valve – PF-80, w/ Mtg. Flange, Swirl Plate & Screws 1 54179
Gas Valve – PF-110, w/ Mtg. Flange, Swirl Plate & Screws 1 54180
Gas Valve – PF-140, w/ Mtg. Flange, Swirl Plate & Screws 1 54181
Vent Termination Kits
– 3"SS Vent Termination Kit 1 54161
– 4"SS Vent Termination Kit 1 91401
– CPVC Vent/Inlet Adapter 1 54135
– Poly-Propylene Vent/Inlet Adapter 1 54155
– 3" Vent Perf Stainless Steel Screen 1 54150
– PVC 3" DWV P400-030 Tee 1 54151
– PVC 3" DWV P100-030 Coupling 1 54152
– PVC 3" Concentric Termination 1 91403
Poly-Propylene Venting
–
80/125mm White Concentric Sidewall Vent kit – Includes Concentric Vent Termination,
Outer Wall Bracket, Inner Wall Bracket with Securing Tab and Screws
– 54396
–
100/150mm White Concentric Sidewall Vent kit – Includes Concentric Vent Termination, Outer Wall Bracket,
Inner Wall Bracket with Securing Tab and Screws
– 54397
– 80/125mm White, Black Concentric Vertical Termination – 54398
– 100/150mm White, Black Concentric Vertical Termination – 54399
– 80/100 White Concentric 90 Degree Elbow with Locking Band – 54085
– 100/150 White Concentric 90 Degree Elbow with Locking Band – 54435
–
Concentric Adapter Kit – 3" PVC to 80/125mm – Kit Includes 2 PVC to PP Adapters,
1 Two-pipe Adapter and (1) 80 x 500mm PP Pipe Length
– 54296
–
Concentric Adapter Kit – 4" PVC to 100/150mm – Kit Includes 2 PVC to PP Adapters,
1 Two-pipe Adapter and (1) 100 x 500mm PP Pipe Length
– 54297
Miscellaneous
– Large Hose Clamp 1 54138
– Small Hose Clamp 1 54139
– Condensate Neutralizer 1 54121
– Electric Panel MNT Receptacle 1 54136
– Burner Mounting Plate Kit PUREFIRE 1 54128
– Switch Condensate Float w/ Cap Switch 1 54137
– Condensate Collector 1 54120
– Wall Mounting Kit 1 5636
– Gas Line Flex Kit w/ 1-1/2" NPT 1 54203
