REPAIR PARTS
Description
Quantity
Required
Stock
Code
1 Intermediate Section – w/out Draw Lugs – 90028
2 Intermediate Section – w/ Draw Lugs (64) – 90029
3 Right Hand Section – 90030
4 Left Hand Section – 90031
5 Draw Rod 5/8"-11 x 8" (64) – 7797
6 Draw Rod Nut 5/8"-11 (64) – 51567
7 Draw Rod Washer (64) – 7289
8 2" Push Nipple – 51543
9 6" Push Nipple – 51546
10 High Temperature Sealing Rope 1/2" – 51211
– 63-03L Block Assembly – 90684
– 63-03 Block Assembly – 90684
– 63-04L Block Assembly – 90685
– 63-04 Block Assembly – 90685
– 63-05L Block Assembly – 90686
– 63-05 Block Assembly – 90686
– 63-06 Block Assembly – 90687
– Left Hand 64-07 Split Block – 90904
– Right Hand 64-07 Split Block – 90906
– Left Hand 64-08 Split Block – 90904
– Right Hand 64-08 Split Block – 90907
– Left Hand 64-09 Split Block – 90904
– Right Hand 64-09 Split Block – 90908
– Left Hand 64-10 Split Block – 90905
– Right Hand 64-10 Split Block – 90907
– Left Hand 64-11 Split Block – 90905
– Right Hand 64-11 Split Block – 90908
– Left Hand 64-12 Split Block – 90905
– Right Hand 64-12 Split Block – 90909
11
Base Front Panel – 63-03 – 50324
Base Front Panel – 63-04 – 50325
Base Front Panel – 63-05 – 50326
Base Front Panel – 63-06 – 50327
Base Front Panel – 64-07 – 50328
Base Front Panel – 64-08 – 50329
Base Front Panel – 64-09 – 50330
Base Front Panel – 64-10 – 50331
Base Front Panel – 64-11 – 50332
Base Front Panel – 64-12 – 50333
12
Base Rear Panel – 63-03 – 61180
Base Rear Panel – 63-04 – 61181
Base Rear Panel – 63-05 – 61182
Base Rear Panel – 63-06 – 61183
Base Rear Panel – 64-07 – 61184
Base Rear Panel – 64-08 – 61185
Base Rear Panel – 64-09 – 61186
Base Rear Panel – 64-10 – 61187
Base Rear Panel – 64-11 – 61188
Base Rear Panel – 64-12 – 61189
Description
Quantity
Required
Stock
Code
13
Burner Access Panel – 63-03 – 50271
Burner Access Panel – 63-04 – 50272
Burner Access Panel – 63-05 – 50273
Burner Access Panel – 63-06 – 50274
Burner Access Panel – 64-07 – 50275
Burner Access Panel – 64-08 – 50276
Burner Access Panel – 64-09 – 50277
Burner Access Panel – 64-10 – 50278
Burner Access Panel – 64-11 – 50279
Burner Access Panel – 64-12 – 50280
14
Burner Tray Rear Support – 63-03 – 50300
Burner Tray Rear Support – 63-03L – 50301
Burner Tray Rear Support – 63-04 – 50302
Burner Tray Rear Support – 63-04L – 50303
Burner Tray Rear Support – 63-05 – 50304
Burner Tray Rear Support – 63-05L – 50305
Burner Tray Rear Support – 63-06 – 50306
Burner Tray Rear Support – 63-07 – 50307
Burner Tray Rear Support – 63-08 – 50308
Burner Tray Rear Support – 63-09 – 50309
Burner Tray Rear Support – 63-10 – 50310
Burner Tray Rear Support – 63-11 – 50311
Burner Tray Rear Support – 63-12 – 50312
15
Burner Tray Left Side Rail – 50296
Burner Tray Right Side Rail – 50295
16
Burner – 63-03L 2 50192
Burner – 63-03 3 50192
Burner – 63-04L 4 50192
Burner – 63-04 5 50192
Burner – 63-05L 6 50192
Burner – 63-05 7 50192
Burner – 63-06 9 50192
Burner – 64-07 11 50192
Burner – 64-08 13 50192
Burner – 64-09 15 50192
Burner – 64-10 17 50192
Burner – 64-11 19 50192
Burner – 64-12 21 50192
17
Burner with Pilot Bracket (Standing) – 50162
Burner with Pilot Bracket (Spark) – 50163
Table 12.1
