REPAIR PARTS
Description
Quantity
Required
Stock
Code
21
Flue Collector – 63-03 – 50281
Flue Collector – 63-03L – 50282
Flue Collector – 63-04 – 50283
Flue Collector – 63-04L – 50284
Flue Collector – 63-05 – 50285
Flue Collector – 63-05L – 50286
Flue Collector – 63-06 – 50287
Flue Collector – 64-07 – 50288
Flue Collector – 64-08 – 50289
Flue Collector – 64-09 – 50290
Flue Collector – 64-10 – 50291
Flue Collector – 64-11 – 50292
Flue Collector – 64-12 – 50293
22
Draft Hood – 63-03 – 50252
Draft Hood – 63-04 – 50254
Draft Hood – 63-05 – 50256
Draft Hood – 63-06 – 50257
Draft Hood – 64-07 – 50258
Draft Hood – 64-08 – 50259
Draft Hood – 64-09 – 50260
Draft Hood – 64-10 – 50261
Draft Hood – 64-11 – 50262
Draft Hood – 64-12 – 50263
23 Insulation Board – 7956
Conversion Kits Natural to LP Gas
– STDG 63 Series – 90068
– STDG 64-07, 64-08 – 90227
– SPRK 63 – 90070
– SPRK 64 – 90071
Conversion Kit LP to Natural Gas
– STDG 63 – 90067
– STDG 64-07, 64-08 – 90226
– SPRK 63 – 90069
– SPRK 64-07, 64-08 – 90051
– SPRK 64-09, 64-12 – 90052
Vent Dampers
– 63-03 – Effikal-RVGP-6BK – 6" – 90613
– 63-04 – Effikal-RVGP-7BK – 7" – 90614
– 63-05 – Effikal-RVGP-8BK – 8" – 90615
– 63-06 – Effikal-RVGP-9BK – 9" – 90417
– 64-07 – Effikal-RVGP-9BK – 9" – 50167
–
64-08 Thru 64-09 –
Effikal-RVGP-1 0BK – 10"
– 50168
–
64-10 Thru 64-12 –
Effikal-RVGP-1 0BK – 12"
– 90616
Jackets
– 63-03L – 90645
– 63-03 – 90645
– 63-04L – 90646
– 63-04 – 90646
– 63-05L – 90647
– 63-05 – 90647
– 63-06 – 90648
– 64-07 – 90649
– 64-08 – 90650
– 64-09 – 90651
– 64-10 – 90652
– 64-11 – 90653
– 64-12 – 90654
Description
Quantity
Required
Stock
Code
18
Gas Valve – NAT-STDG 63-03/04
Honeywell VR8200A-2116
– 50581
Gas Valve – NAT-STDG 63-05/06
Honeywell VR8300A-4003
– 50587
Gas Valve – NAT-STDG 64-07/08
Honeywell VR8304M-4002*
– 50589
Gas Valve – NAT-SPRK 63-05/06
Honeywell VR8304M-4002
– 50589
Gas Valve – NAT-SPRK 64-07, 64-08
Honeywell VR8304M-4002
– 50589
Gas Valve – NAT-SPRK 63-03, 63-04
Honeywell VR8204A-2001
– 50583
Gas Valve – NAT-SPRK 64-09/64-12
7000DERHC Robert Shaw
– 50247
Gas Valve – LP-STDG 63-03, 63-04
Honeywell VR8200A-2165
– 50582
Gas Valve – LP-STDG 63-05, 63-06
Honeywell VR8300A-4011
– 50588
Gas Valve – LP-SPRK 64-05, 64-06
Honeywell VR8304M-4010
– 50590
Gas Valve – LP-STDG 64-07, 64-08
Honeywell VR8300C-4035
– 91333
Gas Valve – LP-SPRK 64-07, 64-08
Honeywell VR8304P-4314
– 50724
Gas Valve – LP-SPRK 64-09, 64-12
Honeywell VR8304P-4314
– 50724
Gas Valve – LP-SPRK 63-03, 63-04
Honeywell VR8204A-2183
– 50584
*denotes valve requires L62 Pilot Module – 50755
19
Pilot Assembly NAT-STDG 63-03/63-06
5CH Robert Shaw
– 50248
Pilot Assembly NAT-STDG 64-07/64-12
Honeywell Q327A-1006
– 50556
Pilot Assembly NAT-SPRK 63/64
Honeywell Q348A-1358
– 50558
Pilot Assembly LP-STDG 63-03/63-06
5CH Robert shaw
– 50249
Pilot Assembly LP-STDG 64-07/64-12
Honeywell Q327A-1147
– 50557
Pilot Assembly LP-SPRK 63/64
Honeywell Q348A-1358
– 51814
– Ignition Cable Honeywell 394800-30 – 50640
–
Vent Safety Switch (3L, 3, 4L)
1 NT08L-5621-210°F
– 50040
–
Vent Safety Switch (4-12; not 4L)
1 NT08L-5621-230°F
– 50041
– Ignition Control (non-CSD) UT1 003-632A – 50250
– Ignition Control (CSD) UT1 003-61 0A – 50706
– Lock-Out Module (CSD) UT1 145-2-1 – 50707
– Thermocouple K1 6BA-24D (24) 3-6 – 50838
– Thermocouple K1 5DA-36 (36) 7-8 – 50839
20
Gas Manifold – 63-03L – 50265
Gas Manifold – 63-04 – 50266
Gas Manifold – 63-04L – 50267
Gas Manifold – 63-05 – 50268
Gas Manifold – 63-05L – 50269
Gas Manifold – 63-06 – 50270
Gas Manifold – 64-07 Assembly Kit – 90411
Gas Manifold – 64-08 Assembly Kit – 90412
Gas Manifold – 64-09 Assembly Kit – 90413
Gas Manifold – 64-10 Assembly Kit – 90414
Gas Manifold – 64-11 Assembly Kit – 90415
Gas Manifold – 64-12 Assembly Kit – 90416
Table 12.2
