BOILER SET-UP
A. SETTING THE BOILER
1. Prepare sketches and notes of the layout of the
installation. Include boiler location, venting system,
existing piping and wiring. Show existing equipment
that may interfere with installation of new
equipment. See Section 4-A. “Vent System
Installation,” Page 7, and Figure 4.1.
2. Provide a level foundation, located as close as
possible to the center of the heating system.
3. This boiler is suitable for use on combustible
flooring, provided the boiler is not set on carpet and
a metal drip pan is placed under the appliance.
4. See exploded view (Figure 9.1). After uncrating
boiler and setting it on foundation, open burner
mounting plate (Item 5) and make certain the target
wall (Item 2) is seated in the back of the combustion
chamber. (WV-DV-04) Ceramic fiber blanket base
liner (Item 3) should be lying flat on bottom of
combustion chamber between target wall and burner
mounting plate. Close burner mounting plate.
