• Child car seat base, group 0+, “Semi-Universal”
category, class E for use with any models of
the car seats "Primo Viaggio Tri-Fix", "Primo
Viaggio SL" . Approved under European
standard ECE R44/04 for children weighing
from 0 to 13 kg (0 to 12/14 months). Only for
use in vehicles fitted with Isofix approved
points (for details see the list of car models
fitted with Isofix attachment systems).
• Child car seat base, group 1, “Semi-Universal”
category, class A for use with Viaggio1 Duo-Fix
and all its models. Approved under European
standard ECE R44/04 for children weighing
from 9 to 18 kg (from 9 months to 4 years
approx). It can only be used in vehicles with
approved Isofix points.
• Check the vehicle's use and maintenance
manual to see whether it is compatible with
Isofix child restraint systems.
• If you are unsure of anything, contact the
manufacturer or the retailer of this child car
seat.
• Do not remove the stickers; this could mean
that the product no longer conforms with
standards.
• Do not use this base if it is broken or has
missing parts, if it is second-hand or of
uncertain origin, or if it has undergone violent
strain in an accident, as it may have suffered
extremely dangerous structural damage.
• Do not modify the product.
• For any repairs, replacement parts or
information on the product, contact the
post-sales assistance service. The relevant
information is provided on the last page of this
manual.
• Do not use this base after a period of five
years has passed from the date of production
indicated on the bottom. The natural ageing
of the materials may mean that it is no longer
compliant with standards.
Instructions for use in car
1• Find the Isofix attachment points on the car
seats.
2• Lengthen the Isofix attachments on the base
by pressing the lever as shown in the figure, to
facilitate fastening.
3• Extract the support leg from under the base
and fold it outwards until it clicks into position.
Position the base on the car seat as shown in
the figure, aligned with the Isofix attachments.
4• Engage the attachments on the base to the
seat buckles (check that there is nothing
interfering with the seat buckles that could
stop them from functioning properly).
•
IMPORTANT: The two signals on the sides
of the handle go from red to green to indicate
that it is properly attached.
• IMPORTANT: Once the procedure is
complete, move the base to check that both
Isofix points are actually attached.
5• Adjust the height of the support leg by
pressing down the inner catch until it touches
the car floor (it is important for the leg to be
well supported on the car floor even if this
causes the base to be slightly raised from the
vehicle seat).
• Once the above steps are complete, “Isofix
Base 0+1 K” can remain in the car ready for
use.
• If your car has storage compartments on the
floor of the vehicle, in the area where the support
leg is to rest, you should open the compartment
and rest the leg on the bottom of it.
Connecting Primo Viaggio Tri-
Fix / Primo Viaggio SL
6• Place the child in the car seat safety seat,
remembering to secure him/her with the
harness. Lift the chair with the handle (facing
the opposite direction to normal vehicle
movement) and engage to the base by
pressing down with both hands on the chair
until it clicks into place.
• IMPORTANT: The two signals behind the
base go from red to green to indicate that the
child car seat is properly attached.
• IMPORTANT: Once the procedure is
complete, move the child car seat to check
that it is actually attached.
7• Inside the car, the handle must be fully
lowered towards the backrest of the vehicle
seat, as shown in the figure. Press the round
buttons on the handle and at the same time
rotate the handle as shown in the figure until it
clicks into position.
8• Pull the handle on the base and push the base
