24
number.
• Do not remove the adhesive or sawn
labels. The removal of these labels
could result in the product not being
compliant with standards.
• Do not use the child car seat if it is
broken or if there are missing parts,
if it is second-hand or if it has been
subjected to heavy impacts as a
result of accidents, because it may be
structurally damaged.
• Do not alter the product.
• Contact the post-sales service for
reparations, the replacement of
components and information on the
product.
Refer to the last page of this manual for
further information.
If the child car seat has been fixed in
place with Isofix fittings, do not detach
it from the fittings.
If the car seat has been fixed in place
with safety belts only, it is possible to
remove it and store it in the luggage
compartment if unused.
• Do not use this car seat after 12 years
from the date of production indicated
on the structure. The natural ageing
of the materials may mean that it is no
longer compliant with standards.
• Do not use accessories that have not
been approved by the manufacturer or
competent authorities.
1_ IMPORTANT
• "Viaggio 2/3": this car seat,
group 2/3, must be installed in the
direction of travel.
• Do not install “Viaggio 2/3” in an
opposite or transversal location as
compared to the direction of travel.
• It is always advisable to fit the child
seat on the rear seats and on the
passenger’s side.
• If the child seat is installed on the
front seat, it is advisable to place it as
far as possible from the dashboard.
If you experience problems during
the installation of Viaggio 2/3,
try lifting the headrest without
removing it.
Components of the product
2. Inspect the content of the package
and contact the Customer Care if some
items are missing.
_ The child car seat includes: 1 headrest
(a), 1 backrest (b), 1 seat (c).
Backrest and headrest are factory
assembled. To assemble correctly the
product please follow the instructions
carefully.
Product assembly prior
to use
3. Rotate the red stops in the open
position and slide the backrest in the
housings located behind the seat as
shown in the picture.
4. Keeping the product flat, close the
red stops until a click is heard.
5• Lift the backrest of the child seat
until you hear it click (Fig. A).
The backrest can move between the
two locks, as indicated in figure B.
When the operation is completed, the
product is free-standing.
Features of the product
6• The headrest can be adjusted in 6
positions. Lift the handle on the rear
of the backrest and position it at the
desired height.
IMPORTANT: as the child grows,
it is necessary to adjust the height
according to the stature of the
child.
IMPORTANT: after completing
the operation, try moving the
headrest to verify that it is correctly
fitted in place.
7• Viaggio2/3 is fitted with two lateral
and removable drink holders.
8• Viaggio2/3 is fitted with a reclination
system that guarantees maximum
comfort. To recline the seat, pull the
handle on the front and simultaneously
lift the seat.
9• If possible, recline the car’s backrest
while the child is asleep and then
recline the backrest of the child seat to
the same slant.
The Viaggio 2/3 backrest will adapt to the
slant of the car’s backrest, guaranteeing
greater comfort for your child.
Fitting the child car seat
with the safety belts and
Surefix fittings
For cars fitted with Isofix
hooks
This method can be used only if the car
is fitted with Isofix hooks.
For further information on the
availability of these hooks and their
location, refer to the instruction manual
of the car. Surefix fittings guarantee
a greater safety, but cannot replace
To Next Page
