6.1
6.2
TeleNET MONITORING/SUPERVISION SYSTEM
For TeleNET connections follow the scheme below. Refer to TeleNET user manual for
instrument configuration.
WARNING: During configuration, at entry “Module” to select the entry "Instrument ECP
Base Series / ECP Expert Series rel. 25 or higher".
NET CONFIGURATION WITH MODBUS-RTU PROTOCOL
For RS485 connections with Modbus-RTU protocol follow the scheme below.
Refer to MODBUS-RTU_ECP202EXP user manual for MODBUS-RTU communication
protocol specification.
CHAPTER 6: OPTIONAL KIT
CHAP. 6 - Optional kit
