Pego ECP202 EXPERT Use And Maintenance Manual

ECP202 EXPERT
Pag. 8
USE AND MAINTENANCE MANUAL
Rev. 01-19
TECHNICAL CHARACTERISTICS
Power supply
Voltage
230 V~  10% 50/60Hz
Max power (only electronics)
~ 7 VA
Rated current (with all loads connected)
16A
Climatic conditions
Working temperature
-5 ÷ +50°C
Storage temperature
-10 ÷ +70°C
Relative ambient humidity
Lower than 90% Hr
General characteristics
Type of sensors that can be connected
NTC 10K 1%
Resolution
0,1 °C.
Sensor read precision
± 0,5 °C
Read range
-45 ÷ +99 °C
Output characteristics
Description
Installed relay
Card output characteristics
Note
Compressor
(Relay 30A AC1)
10A 250V~ (AC3) (2HP)
(100000 cicli)
The sum of
contemporary
absorptions of
these outputs
has not to
exceed 16A
Defrost
(Relay 30A AC1)
16A 250V~ (AC1)
Fans
(Relay 16A AC1)
2,7A 250V~ (AC3)
Room light
(Relay 16A AC1)
16A 250V~ (AC1)
Aux 1
(free voltage contact)
(Relay 5A AC1)
5(3)A 250V~
Aux 2
(free voltage contact)
(Relay 5A AC1)
5(3)A 250V~
General electrical protection
Differential magnetothermic circuit breaker 16A
Id=300 mA
(Id=30 mA on request)
Disconnecting power 4.5 kA
Dimensional characteristics
Dimensions
18.0cm x 9.6cm x 26.3cm (HxPxL)
Insulation and mechanical characteristics
Box protection rating
IP65
Box material
ABS self-extinguishing
Type of insulation
Class II
CHAP. 3 - Technical characteristics
CHAPTER 3: TECHNICAL CHARACTERISTICS
3.1
