Pelco Spectra - PARK; PROGRAMMING THE SPECTRA (VERSION 3.0)

18 Pelco Manual C1490M (10/98)
The output relay can also be programmed so that it is activated when any alarm
input is activated. When latching (toggling) is selected on the programming menu,
giving the AUX 1 command from the controller changes the state of the AUX (for
example, if it was on, this turns it off.) The clear command from the controller will
turn the AUX off in the latching or toggle mode.
4.10 PARK
If the dome does not receive any commands for a specified period, it goes to preset
1 and parks. The dome will not park if the time specified is zero or preset 1 has not
been programmed. The default is zero minutes.
4.11 PROGRAMMING THE SPECTRA
®
(VERSION 3.0)
The dome can be programmed for the following functions:
AGC (automatic gain control) Auto park time Power-up mode
Alarm dwell Auxiliary relays Proportional panning
Alarm pattern Backlight compensation Scan speed
Alarm priority Camera reset Sharpness
Alarm resume Gain Shutter speed
Auto flip disable Limit stops Video zone blanking
Auto focus Pattern length White balance
Auto iris Power line synchronization Zoom limit
The main menu contains six secondary menus: Camera, Line Sync, Power Up
Mode, Aux, Alarms, Zone Blank, and Other. Each secondary menu has submenus,
which are structured as shown below. Beside the menu items are section numbers
in parentheses showing where the functions are explained.
1. Camera
First Camera Submenu Second Camera Submenu
Backlight comp (4.11.2) Shutter speed (4.11.7)
Zoom limit (4.11.3) Auto focus mode (4.11.8)
Reset camera (4.11.4) Sharpness (4.11.9)
Gain/AGC (4.11.5) Auto sharpness
AGC mode Sharpness
Gain White balance (4.11.10)
Auto-iris (4.11.6) Auto white bal
Auto-iris mode R-B white bal
Auto-iris level M-G white bal
Auto-iris peak Prev (to first camera submenu)
Next (to second camera submenu)
2. Line Sync (4.11.11) 3. Power Up (4.11.12)
Line sync Power Up
Line sync phase
4. Aux (4.11.13) 5. Alarm, Zone Blank
Aux 1 mode Alarm resume (4.11.14)
Aux 2 mode Alarm dwell sec (4.11.15)
Alarm priority (4.11.16)
Alarm pattern (4.11.17)
Zone blank (4.11.18)
6. Other
Auto flip (4.11.19)
Proportional pan (4.11.20)
Limit stops (4.11.21)
Park time minutes (4.11.22)
Scan speed deg/s (4.11.23)
Pattern length (4.11.24)
The following sections explain how to program the Spectra
®
(Version 3.0) dome
using the menu choices.
