26 Pelco Manual C1490M (10/98)
To change the alarm pattern:
1. On the main menu, move the joystick up or down to position the cursor (>)
beside Alarms, Zone Blank.
2. Press the Iris Open button to enter the Alarms, Zone Blank submenu.
3. Move the joystick up or down to position the cursor beside Alarm Pattern.
4. Press the Iris Open button to enter the Alarm Pattern submenu.
5. Move the joystick up or down to position the cursor beside the number of the
alarm input for which you want to set the pattern.
6. Press the Iris Open button. The cursor will move to the right beside the words
Full Pat, Half Pat 1, Half Pat 2, or No Pattern.
7. Move the joystick up or down to toggle between the choices.
8. SELECT - Press the Iris Open button on your keyboard to select your choice.
CANCEL - Press the Iris Close button if you do not want to change the setting.
4.11.18 Zone Blank
This feature lets you define any of eight zones as blanked for video when the cam-
era pans into the zone area. The choices are on (video blanking is in effect) and off.
The default is off. To change the blank zone setting:
1. On the main menu, move the joystick up or down to position the cursor (>)
beside Alarms, Zone Blank.
2. Press the Iris Open button to enter the Alarms, Zone Blank submenu.
3. Move the joystick up or down to position the cursor beside Zone Blank.
4. Press the Iris Open button to enter the Zone Blank submenu.
5. Move the joystick up or down to position the cursor beside the number of the
zone for which you want to set the blank option.
6. Press the Iris Open button. The cursor will move to the right beside the word
On or Off.
7. Move the joystick up or down to toggle between the words On and Off.
8. SELECT - Press the Iris Open button on your keyboard to select your choice.
CANCEL - Press the Iris Close button if you do not want to change the setting.
4.11.19 Auto Flip
The two auto flip modes are on (auto flip feature enabled) or off (feature disabled).
To change the auto flip mode:
1. On the main menu, move the joystick up or down to position the cursor (>)
beside Other.
2. Press the Iris Open button to enter the Other submenu.
3. Move the joystick up or down to position the cursor beside Auto Flip.
4. Press the Iris Open button. The cursor moves to the right beside the word On
or Off.
5. Move the joystick up or down to toggle between On and Off.
6. SELECT - Press the Iris Open button to select your choice.
CANCEL - Press the Iris Close button if you do not want to change the setting.
4.11.20 Proportional Pan
The two proportional pan modes are on or off. When proportional pan mode is on,
the proportional pan feature is enabled and the pan (and tilt) speed depends on the
amount of zoom. At telephoto zoom settings the pan (and tilt) speeds will be slower
for a given amount of joystick deflection than at wide zoom settings. This keeps the
image from moving too fast on the monitor when there is a large amount of zoom.
This slowing does not happen when going to a preset, but does occur in turbo
mode when high zoom is selected.
