DESCRIPTION AND TECHNICAL CHARACTERISTICS
TECHNICAL CHARACTERISTICS
Excelion 1200
Model Version
MULTI-CUT
Lawnmower
Version
MULTI-CUT
Two-pronged blade
Power 1,200 W
Weight (without cutting tool and safety casing) 3.8 Kg 3.9 Kg
Dimensions (L x w x H) in mm 1360 x 85 x 210 1360 x 85 x 210
Cutting diameter 300 mm 230 mm
Rotation speed 2,000 to 6,200
Working capacity (time) According to use and battery type
Vibration emission value as per EN 60745-1, EN ISO 22867.
handle
a
h
≤2,5m/s²
uncertainty
K
d
=1,5m/s²
Determining the sound levels and vibration rates is based on the operating conditions at the maximum nominal rating.
Symbol Value Unit Reference Comment
L
WAm
90 dB(A) 1 pW Measuredsoundpowerlevel
L
WAg
91 dB(A) 1 pW Guaranteed sound power level
The recording of the measured sound power level and of the guaranteed sound power level has been performed according to a
procedure in accordance with directive 2000/14/CE appendix V.
MaximumA-weightedsoundpressurelevel(ref.20µPa)atthepositionoftheuser L
pA
= 83 dB(A) K = 2,5 dB(A)
C-weightedpeaksoundpressure(ref.20µPa)atthepositionoftheuser L
pC
< 130 dB(C)
ValuesdenedaspersoundmeasurementstandardsNFENISO11201andNFENISO3744.
REMARK:
Safety element assembly/disassembly procedures only require the adjustment key supplied with the
Excelion 1200 grass cutting brush-cutter.
The cutting head assembly/disassembly procedures require circlip pliers (not supplied).
Consultthe"Maintenance"sectiontondthePellencpartnumbersforpartstobereplaced(seepage30).
PREPARING THE MACHINE FOR USE
