USING THE PELOTON GUIDE
CAMERA
When the Guides camera is in use, the status light will turn green. The camera is only in use when you are in a class with the camera
cover open and Self Mode (see p. 25) turned on.
When the Guide is powered on, but the camera is not in use, the status light will be white. To shut the camera off completely, slide the
camera cover over the lens.
MICROPHONE
The Guides microphone is used only for listening to voice commands during a class. To disable the microphone and turn off voice
control, toggle the switch on the back of the Guide.
POWER
To shut down the Guide, press or to open the main menu. Navigate to the bottom of the menu and select power symbol.
The Guide will also shut itself off after about 15 minutes of inactivity. To set a longer time-out period, navigate to Settings › Screen ›
Auto-Sleep.
To wake the Guide, press any button on the remote. If the Guide and remote are both asleep, you may need two button-presses to wake
the system.
USING THE PELOTON GUIDE | 21

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Peloton GUIDE and is the answer not in the manual?

Peloton GUIDE Specifications

General IconGeneral
ConnectivityWi-Fi 802.11 a/b/g/n/ac, Bluetooth 5.0
CompatibilityTV with HDMI port
Field of View120 degrees
Microphones4-microphone array
PowerUSB-C
RAM2 GB
Camera12 MP
AudioN/A (relies on TV audio)
Dimensions6.7" L x 2.2" W x 2.0" H
Weight0.6 lbs
DisplayNot applicable
PortsHDMI
