Pelpro PP70 - Glass Specifications; Electrical Rating (on High); BTU & Efficiency Specifications; Stove Dimensions

PelPro Pellet Stove • 7103-171C • 11/1/18
pelprostoves.com
37
Listing and Code Approvals
Listings and Certications
Glass Specications
This Stove is equipped with 5mm ceramic glass.
Replace glass only with 5mm ceramic glass. Please contact PelPro for replacement glass.
Electrical Rating (On High)
PP70: 120 VAC, 60 Hz, Start 2.6 Amps,
Run 2.3 Amps
This manual describes the installation
and operation of the Brand PelPro,
Model PP70 wood Stove. This Stove
meets the 2020 U.S. Environmental
Protection Agency’s crib wood
emission limits for wood Stoves sold
after May 15, 2020. Under specic test
conditions this Stove has been shown
to deliver heat at rates ranging from
9,603 to 35,278 Btu/hr.
BTU & E󰀩ciency Specications
Emissions Report No. 0135PS040E
EPA Certicatin # 129-18
EPA Certied
Emmissions
0.49 grams/hr
*LHV Tested E󰀩ciency 88.5%
**HHV Tested E󰀩ciency 82.8%
***EPA BTU Output 9,603 - 35,278 / hr
****BTU Input 11,676 - 42,535 / hr
*****Heating Capacity
up to 2000 sq. ft.
depending on climate zone
Vent Size 3” or 4” L or PL
Hopper Capacity 70 lbs (Approximate)
Fuel Premium Wood Pellets
Shipping Weight 198.4 lbs
3-1/2 in
(89mm)
2-3/8 in
(60mm)
21-15/16 in
(557mm)
21-3/4 in (552mm)
21-3/4 in (552mm)21-3/4 in (552mm)
33 in
(838mm)
10-1/2 in
(268mm)
AIR INLET
21-1/2 in (547mm)
22-5/16 in (567mm)
22-1/16 in (561mm)
9-1/4 in
(235mm)
FLUE
Stove dimensions
Stove Dimensions
*Weighted average LHV e󰀩ciency using data collected during EPA emissions test.
**Weighted average HHV e󰀩ciency using data collected during EPA emissions test.
***Maximum BTU output based on HHV e󰀩ciency and the high burn section of the EPA emissions test.
****Maximum BTU input based on the high burn section of the EPA emissions test.
*****Heating capacity depencs on climate zone, structure layout, insulation, windows, etc.
