Pelpro PP70 - Placing Your Stove

PelPro Pellet Stove • 7103-171C • 11/1/18
pelprostoves.com
9
Installing Your Stove
Installing Your Stove
2
B*
A
C
A
Placing Your Stove
1
1
2
Notice: Be careful to protect the bottom of the Stove and oor surfaces when moving the Stove. Bottom
edges of Stove are sharp and can scratch surfaces.
Notice: Clearances may only be reduced by means approved by the regulatory authority having jurisdiction.
USA Hearth Pad Requirements Inches mm
A Sides 2 51
B Back 2 51
C Front 6 152
Non-combustible oor protection extending beneath the ue pipe is required with horizontal venting or under the top vent
adapter with vertical installation.
*Non-combustible oor protection must extend 2 inches (51mm) beneath the ue pipe when installed horizontal venting or
under the top vent adapter with vertical installation. CANADA REQUIRED, USA RECOMMENDED.
Canada Hearth Pad Requirements Inches mm
A Sides 6 152
B Back 2 51
C Front 6 152
Hearth pad minimum requirements:
It is necessary to install EMBER PROTECTION; a Type 1 oor protector for this Stove.
The Floor protector must be non-combustible material, extending beneath Stove with a
minimum of 6 inches (152mm) in front of glass and 6 inches (152mm) to both sides of
the fuel loading door. Open the door and measure 6 inches (152mm) from the side edge
of the opening in the face of the Stove.
