PelPro Cast Pellet Stove • 7093-600J • 04/21 PelPro Cast Pellet Stove • 7093-600J • 04/21pelprostoves.com pelprostoves.com2 3
Vacuum SwitchDigital Control
Ambient Probe
Convection Blower
Outside Air
Connection
Optional External
Thermonstat Connection
Vacuum Switch
Exhaust Blower
Exhaust Probe
Exhaust
Connection
Snap Disc
Drop Tube
Firepot
Igniter
(Behind Firepot)
Baffles (3)
WARNING
This product and the fuels used to operate this product (wood), and
the products of combustion of such fuels, can expose you to
chemicals including carbon black, which is known to the State of
California to cause cancer, and carbon monoxide, which is known to
the State of California to cause birth defects or other reproductive
harm. For more information go to: WWW.P65Warnings.ca.gov
Safety First!
Safety Alert Key: It is important to pay attention to alerts you will see throughout this manual to ensure your
safety.
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the Stove or to property.
• Pro Tip: Indicates additional information to help you better understand your Stove and optimize its performance.
California - Prop65
NOTICE:
Fire Risk
Pelpro disclaims any responsibility, and the warranty and agency listing will be voided, by the below actions.
DO NOT:
- Install or operate damaged Stove
- Modify Stove
- Install other than as instructed by the manufacturer
- Operate the Stove without fully assembling all components
- Over re (burning at higher temperatures than recommended causing permanent damage to the Stove)
- Install any component not approved by the manufacturer
- Install parts or components not listed or approved
- Disable safety switches
Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. For assis-
tance or additional information, consult a qualied installer, service agency or your dealer.
DANGER!
HOT SURFACES!
Glass and other surfaces are hot during operation AND cool down.
Hot glass will cause burns.
- Do not touch glass until it is cooled
- NEVER allow children to touch glass
- Keep children away; if you expect that children may come into contact with this Stove, we recommend a barrier
such as a decorative screen (see your retailer for suggestions)
- CAREFULLY SUPERVISE children in same room as Stove
- Alert children and adults to hazards of high temperatures
High temperatures may ignite clothing or other ammable materials.
- Keep clothing, furniture, draperies and other ammable materials away
Get to Know Your Stove
Get to Know Your PelPro
®
Stove
Table of Contents
• Get to Know Your Stove
• California - Prop65
Getting Started ...........................................4
• Pallet Removal
• What’s Included
• What You’ll Need
Using Your Stove .........................................6
• Getting Ready
• Vent Termination Clearances
• Placing Your Stove
• Venting Your Stove
Using Your Stove ........................................13
• Fuel Tips
• Starting your Stove the rst time
• Starting your Stove from an empty hopper
• Trim Adjustment
• Turning Your Stove Off
Maintaining Your Stove ...................................18
• Cleaning & Maintenance
• What You’ll Need
• Where, When and How
Replacement Parts .......................................22
Troubleshooting .........................................26
• Power Related
• Blockage Related
• Warranty
Support ................................................31
• Contact information
• Ordering Parts
Listings and Certications ................................32
• Stove Certication
• Mobile Home Approved
• Glass Specications
• Electrical Rating (On High)
• BTU & Efciency Specications
• Stove dimensions
• Warranty
Reference Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
• Service Part List
• Maintenance Log
