This chart lists the NEMA frame sizes for
each combination of HP, phase, voltage,
enclosure and speed confi guration. Verify
the NEMA frame size for the desired motor
and compare to the maximum motor frame
size listed on the individual fan data page in
this brochure.
P Series Direct Drive Motor Availability
and Lek-Trol
™
Controller Availability
Breezex Direct Drive Motor Availability
(1) Nominal 1140 RPM. (2) 50/60 Hz. (3) 60 Hz.
MODEL
NOM
HP
NOMINAL RPM 115/1/60 ODP 230/1/60 ODP TE 115/200/240/1
1050 1300 1550 1650 AVAIL LEK-TROL AVAIL LEK-TROL AVAIL LEK-TROL
P10VA 1/30 X YES LT30 NA NA
P10RA 1/12 X YES LT30 USE TE LT35 YES (2) LT30/35*
P12VA 1/12 X YES LT30 NA NA
P12RA 1/4 X YES LT50 USE TE LT35 YES (2) LT30/35*
P16VA 1/3 X YES NA NA
P16SA 1/2 X YES LT50 NA NA
P16RA 1/2 X YES LT40 USE TE NA YES (2) NA
P16Q1A 3/4 X YES LT60 USE TE NA YES (2) NA
P18VA 1/2 X YES NA NA NA
P18RA 3/4 X YES NA NA NA
P20TA 3/4 X (1) USE TE NA USE TE NA YES (2) NA
P20SA 1 X YES NA YES NA NA
P24VA 3/4 X USE TE NA USE TE NA YES (2) NA
*LT30 - 115
*LT35 - 200/240
HP
SINGLE PHASE 220V, 230V, 460V or 575V THREE PHASE
OPEN DRIP PROOF TE
EXPL
PROOF
2 SPEED
2 WDG
OPEN
DRIP PRF
TE
EXPL
PROOF
2 SPEED
2 WDG
115 V 230 V 115/230
1/4
48 58 58 48/56 48 48 48 48 —
1/3 48/56 48/56 56 56 56 56 56 56 —
1/2 48/56 48/56 56 56 56 56 56 56 56
56 56 56 56 56 56 56 56 56
1 56 56 56 56 56 56 56 56 145T
1 1/2 56 56 145T 184T — 56 56 56 182T
2 145T 145T 182T 182T — 56/145T 145T 145T 182T
3 184T 184T 184T 215T — 145T 182T 182T 184T
5 — — — — — 184T 184T 184T 215T
7 1/2 — — — — — 213T 213T 213T 215T
10 — — — — — 215T 215T 215T 256T
15 — — — — — 254T 254T 254T 284T
20 — — — — — 256T 256T 256T 284T
MODEL
NOMINAL
HP
RPM SINGLE PHASE
THREE PHASE,
230/460V
1140 1725
TE (A),
115V only
EXPL. PROOF
115 or 230V
TE (A)
EXPL.
PROOF
BX12Q
1/6 X Y Y Y N
BX14Q XY Y Y N
BX16T XYY (B)YN
BX16Q 1/3 X Y Y Y Y
BX18T XYYYN
BX18Q XY Y Y Y
BX20T XYYYN
BX20Q 1/3 X Y Y Y Y
BX24T XYY (C)YY
BX24Q XY Y Y Y
A. Use TE for ODP applications. B. Uses 1/4 HP C. Uses 1/2 HP
Motor Selection
Breezeway
On horsepowers less than 1 1/2, motor frame sizes may change due to variations in voltage, special
features and motor manufacturer. Motors shown are ball bearing, continuous duty and 1750 RPM or
1750/1140 RPM for two speed - two winding motors.
NEMA – Motor Frame Size
