PENNBARRY
44
P Series
Direct drive Axial Panel exhaust or supply fan shall be
Breezeway P manufactured by PennBarry, Richardson,
Texas. Motors are rigidly mounted on a heavy gauge
wire basket/rear guard of concentric rings meeting OSHA
specifi cation. Vibration isolation is provided between the
motor/guard assembly and a coated steel fan panel featuring
welded corners, pre-punched mounting holes, and a deeply
spun venturi. Statically balanced propellers are die formed
aluminum. Motors shall be continuous duty, multi-speed (for
applicable models) and permanently lubricated. Each fan
shall bear the AMCA Licensed Ratings Seal for Air and Sound
Performance, and shall be UL and CSA Listed.
Breezex
Direct drive Axial Panel exhaust or supply fan shall be
Breezeway BX manufactured by PennBarry, Richardson,
Texas. Motors are installed on a heavy gauge mounting plate
welded to a formed heavy wall tubular frame, welded onto a
coated steel fan panel featuring welded corners, pre-punched
mounting holes, and a deeply spun venturi. Statically balanced
propellers are aluminum. Motors shall be Totally Enclosed
(TE), continuous duty, ball bearing design, include thermal
overload protection and be reversible. A reversing switch shall
be supplied. (Explosion Proof, Cls. 1, Div. 1, Grp. D, optionally
available; reversing switch by others.)
Type BC
Direct drive Axial Panel exhaust or supply fan shall be
Breezeway BC manufactured by PennBarry, Richardson,
Texas. A heavy gauge motor mounting platform is supported
by formed integral stiffening flanges and welded onto a
coated steel fan panel featuring welded corners, pre-punched
mounting holes, and a deeply spun venturi. Statically balanced
propellers shall be cast aluminum and airfoil shaped. Motors
shall be continuous duty, ball bearing design, positively cooled
and furnished at the specifi ed voltage and phase.
Type BLL
Belt driven Axial Panel exhaust fan shall be Breezeway BLL
manufactured by PennBarry, Richardson, Texas. A heavy
gauge motor mounting platform is supported by formed
integral stiffening fl anges and welded onto a coated steel fan
panel featuring welded corners, pre-punched mounting holes,
and a deeply spun venturi. Statically balanced propellers
shall be heavy gage steel. Motors shall be continuous duty,
ball bearing design, and positively cooled, furnished at the
specifi ed voltage, phase, and enclosure. Shafts shall be
turned, ground, polished, & rust protected. Heavy duty ball
bearings are rated for a minimum L50 life exceeding 200,000
hours. Pulleys shall be adjustable, cast iron, machined, keyed,
securely attached and sized for 150% of the horsepower at
its rated maximum speed. Each fan shall bear the AMCA
Licensed Ratings Seal for Air and Sound Performance, and
shall be UL and CSA Listed.
Type BHM
Belt driven Axial Panel exhaust or supply fan shall be
Breezeway BHM manufactured by PennBarry, Richardson,
Texas. A heavy gauge motor mounting panel is fastened to
heavy gauge structural channel framework laterally supported
and fastened onto a galvanized steel fan panel featuring
toggle-lock corners, pre-punched mounting holes, and a
deeply spun reverse venturi. Statically balanced propellers
shall be coated heavy gage steel, utilizing a fully welded,
coated heavy gage steel spider. Motors shall be continuous
duty, ball bearing design, and positively cooled, furnished at
the specifi ed voltage, phase, and enclosure. Shafts shall be
turned, ground, polished, and rust protected. Heavy duty ball
bearings are rated for a minimum L50 life exceeding 200,000
hours. Pulleys shall be adjustable, cast iron, machined, keyed,
securely attached and sized for 150% of the horsepower at
its rated maximum speed. Each fan shall bear the AMCA
Licensed Ratings Seal for Air and Sound Performance, and
shall be UL and CSA Listed.
Type BHH
Belt driven Axial Panel exhaust or supply fan shall be
Breezeway BHH manufactured by PennBarry, Richardson,
Texas. A heavy gauge motor mounting panel is fastened to
heavy gauge structural channel framework laterally supported
and fastened onto a galvanized steel fan panel featuring
toggle-lock corners, pre-punched mounting holes, and a
deeply spun reverse venturi. Statically balanced propellers
shall be coated heavy gage steel, utilizing a fully welded,
coated heavy gage steel spider. Motors shall be continuous
duty, ball bearing design and positively cooled, furnished at
the specifi ed voltage, phase and enclosure. Shafts shall be
turned, ground, polished and rust protected. Heavy duty ball
bearings are rated for a minimum L50 life exceeding 200,000
hours. Pulleys shall be adjustable, cast iron, machined, keyed,
securely attached and sized for 150% of the horsepower at
its rated maximum speed. Each fan shall bear the AMCA
Licensed Ratings Seal for Air and Sound Performance, and
shall be UL and CSA Listed.
Type BCH
Belt driven Axial Panel exhaust fan shall be Breezeway BCH
manufactured by PennBarry, Richardson, Texas. A heavy
gauge motor mounting panel is welded to heavy gauge
structural angle and tubular welded framework laterally
supported and welded onto a coated steel fan panel featuring
welded corners, pre-punched mounting holes and a deeply
spun venturi. Statically balanced propellers shall be cast
aluminum and airfoil shaped. Motors shall be continuous
duty, ball bearing design, positively cooled and furnished at
the specifi ed voltage, phase and enclosure. Shafts shall be
turned, ground, polished and rust protected. Heavy duty ball
bearings are rated for a minimum L50 life exceeding 200,000
hours. Pulleys shall be adjustable, cast iron, machined, keyed,
securely attached and sized for 150% of the horsepower at
its rated maximum speed. Each fan shall bear the AMCA
Licensed Ratings Seal for Air and Sound Performance, and
shall be UL and CSA Listed.
Sample Specifi cations
Breezeway
