PENNBARRY
19
34
34
2
1
/
2
3
31
18
HP RPM
TIP
SPEED
(FPM)
FAN CAPACITY - CUBIC FEET PER MINUTE (CFM)
0.000" SP 0.100" SP 0.125" SP 0.150" SP 0.200" SP 0.250" SP 0.300" SP 0.375" SP 0.500" SP
Sones BHP Sones BHP Sones BHP Sones BHP Sones BHP Sones BHP Sones BHP Sones BHP Sones BHP
1/4
420 3299
5331 2695 1694 1139
8.2 0.13 8.6 0.13 9.3 0.14 9.9 0.15
445 3495
5648 3612 2296 1581
9.0 0.16 8.9 0.16 9.4 0.16 10.1 0.17
460 3613
5838 3952 2684 1854
9.5 0.17 9.4 0.18 9.7 0.17 10.3 0.18
475 3731
6029 4265 3217 2212
10.0 0.19 9.8 0.20 10.1 0.19 10.6 0.20
490 3848
6219 4565 3861 2576 1404
10.5 0.21 10.4 0.23 10.5 0.22 11.1 0.21 12.3 0.23
505 3966
6409 4861 4211 2978 1665
11.1 0.23 10.9 0.25 11.1 0.24 11.6 0.23 12.8 0.25
520 4084
6600 5127 4543 3508 1939
11.7 0.25 11.6 0.27 11.7 0.27 12.1 0.25 13.3 0.27
531 4170
6739 5320 4767 4029 2138
12.2 0.26 12.0 0.29 12.2 0.29 12.4 0.27 13.7 0.28
1/3
540 4241
6854 5476 4948 4306 2344 1431
12.5 0.28 12.3 0.30 12.5 0.30 12.7 0.29 13.7 0.29 14.9 0.31
560 4398
7108 5819 5344 4765 2835 1782
13.3 0.31 13.2 0.34 13.3 0.34 13.5 0.33 14.2 0.32 15.4 0.34
572 4492
7260 6007 5567 5025 3123 1995
13.8 0.33 13.7 0.36 13.8 0.36 14.0 0.36 14.8 0.33 15.9 0.36
1/2
590 4634
7488 6286 5884 5389 3676 2324 1540
14.7 0.36 14.6 0.39 14.7 0.39 14.9 0.39 15.5 0.37 16.5 0.38 17.6 0.41
610 4791
7742 6594 6231 5787 4504 2776 1893
15.6 0.40 15.6 0.43 15.6 0.44 15.8 0.43 16.3 0.41 17.2 0.42 18.3 0.44
630 4948
7996 6899 6567 6158 5125 3264 2249
16.6 0.44 16.6 0.47 16.6 0.48 16.7 0.48 17.2 0.47 18.1 0.45 19.3 0.48
645 5066
8186 7126 6801 6422 5466 3621 2522
17.4 0.47 17.4 0.50 17.4 0.51 17.5 0.51 17.9 0.51 18.9 0.48 20 0.50
657 5160
8339 7299 6988 6632 5732 4020 2762 1675
18.1 0.50 18.0 0.53 18.0 0.54 18.0 0.54 18.5 0.54 19.5 0.51 21 0.53 22 0.57
3/4
660 5184
8377 7341 7034 6684 5793 4123 2837 1729
18.3 0.51 18.2 0.53 18.1 0.54 18.2 0.55 18.7 0.55 19.6 0.51 21 0.53 22 0.57
675 5301
8567 7551 7265 6943 6097 4704 3208 1994
19.1 0.54 19.0 0.57 19.0 0.58 19.0 0.59 19.5 0.59 20 0.56 21 0.56 23 0.60
695 5459
8821 7830 7571 7270 6497 5509 3692 2341
19.5 0.59 19.5 0.62 19.6 0.63 19.6 0.64 19.9 0.64 20 0.62 22 0.60 23 0.64
710 5576
9011 8038 7799 7504 6793 5862 4067 2618
19.8 0.63 19.9 0.66 19.9 0.67 19.9 0.68 20 0.69 21 0.67 22 0.63 23 0.68
730 5733
9265 8314 8097 7814 7156 6308 4756 2980
20 0.69 20 0.72 20 0.72 20 0.74 21 0.75 21 0.74 22 0.70 23 0.72
745 5851
9456 8520 8307 8044 7420 6621 5417 3348
21 0.73 21 0.76 21 0.77 21 0.78 21 0.79 21 0.79 22 0.75 23 0.76
756 5938
9595 8671 8461 8212 7612 6844 5908 3619 1887
21 0.76 21 0.80 21 0.80 21 0.81 21 0.83 22 0.82 22 0.79 24 0.79 26 0.87
1
770 6048
9773 8862 8656 8425 7854 7124 6239 3959 2136
21 0.80 21 0.84 22 0.85 22 0.85 22 0.87 22 0.87 22 0.85 24 0.82 26 0.90
790 6205
10027 9134 8934 8728 8198 7520 6695 4436 2487
22 0.87 22 0.91 22 0.91 22 0.92 22 0.94 22 0.94 23 0.93 24 0.87 26 0.96
810 6362
10281 9406 9210 9015 8512 7891 7129 5107 2842
23 0.94 22 0.98 23 0.98 23 0.99 23 1.01 23 1.02 23 1.01 24 0.95 27 1.01
Carbon Steel Panel = 16 gauge Wall Opening = 34 3/4 in.sq. Peak BHP = (RPM/741)^3
Galv. Steel Web = 10 gauge Wall Shutter ID = 34 in.sq. Max RPM = 842 (1 HP)
Est. Shipping Weight = 110 lbs Max. Motor Frame Size = 56
AIR FLOW - CFM
STATIC PRESSURE - Inches W.G.
Performance shown is for installation Type A: Free Inlet, Free Outlet. Power rating (BHP) does not include drive losses. The sound ratings shown are for loudness values
in fan sones at 5'0" (1.5m) in a hemispherical free fi eld per AMCA standard 301. Values shown are for installation Type A: Free inlet fan sone levels. Performance ratings
do not include the effects of appurtenances in the airstream. For further information on sound classifi cation, see page 40. For accessories, see pages 3 thru 7.
Belt Drive Fan Data - BLL 30
Breezeway
0
2000 4000 6000
8000 10000
1/4 HP
3/4 HP
1/3 HP
1/2 HP
RPM
BHP
1 H
P
531 RPM
572 RPM
657 RPM
756 RPM
810 RPM
0.400
0.500
0.600
0.700
0.800
0.000
0.200
0.300
0.100
Do not select shaded area.
To Next Page
