PENNBARRY
26
3
5
27
37
1
/
2
44
44
1.500
8000 120004000
0
2000016000
1.250
1.000
0.750
0.500
0.250
0.000
24000 28000
RPM
BHP
2 HP
3 HP
5 HP
759 RPM
901 RPM
662 RPM
Do not select shaded area.
AIR FLOW - CFM
STATIC PRESSURE - Inches W.G.
Galv. Panel = 14 gauge Wall Opening = 44 3/4 in.sq. Peak BHP = (RPM/511)^3
Galv. Mtr. Plate = 12 gauge Est. Shipping Weight = 190 lbs. Max RPM = 929 (5 HP)
Galv. Structure = 12 gauge Max. Motor Frame Size = 215T
HP RPM
TIP
SPEED
(FPM)
FAN CAPACITY - CUBIC FEET PER MINUTE (CFM)
0.000" SP 0.100" SP 0.125" SP 0.200" SP 0.250" SP 0.375" SP 0.500" SP 0.625" SP 0.750" SP
Sones BHP Sones BHP Sones BHP Sones BHP Sones BHP Sones BHP Sones BHP Sones BHP Sones BHP
2
600 5820
17640 16310 15889 14627 13470 9971
17.3 1.47 17.8 1.50 18.1 1.51 18.4 1.54 18.7 1.55 19.2 1.61
620 6014
18228 16964 16557 15387 14347 11251
18.1 1.62 18.5 1.65 18.8 1.66 19.1 1.69 19.4 1.70 19.9 1.76
640 6208
18816 17615 17220 16079 15148 12174
18.9 1.78 19.3 1.81 19.5 1.82 19.9 1.86 20 1.87 21 1.92
662 6421
19462 18327 17946 16834 16011 13196
19.8 1.97 20 2.00 20 2.01 21 2.05 21 2.07 21 2.11
3
685 6645
20139 19064 18699 17617 16901 14257 10010
21 2.18 21 2.22 21 2.23 22 2.26 22 2.29 22 2.33 24 2.41
705 6839
20727 19682 19351 18292 17613 15164 12442
22 2.38 22 2.41 22 2.42 23 2.46 23 2.49 23 2.53 24 2.60
725 7033
21315 20299 20001 18963 18303 16060 13413
23 2.58 23 2.62 23 2.63 24 2.67 24 2.70 24 2.74 25 2.81
740 7178
21756 20760 20486 19463 18817 16724 14103
23 2.75 24 2.79 24 2.80 25 2.84 25 2.86 25 2.91 26 2.97
759 7362
22314 21344 21098 20100 19464 17556 14986
24 2.97 25 3.01 25 3.02 26 3.05 26 3.08 26 3.13 27 3.19
5
790 7663
23226 22293 22060 21134 20511 18796 16418 14027
26 3.34 26 3.39 26 3.40 27 3.44 27 3.46 27 3.52 28 3.57 29 3.65
820 7954
24108 23210 22985 22128 21516 19968 17777 15431
27 3.74 28 3.78 28 3.79 29 3.83 29 3.86 29 3.93 30 3.98 30 4.05
850 8245
24990 24123 23907 23114 22520 21105 19114 16820 14229
29 4.17 29 4.21 30 4.22 30 4.26 31 4.29 31 4.36 31 4.41 32 4.48 33 4.58
880 8536
25872 25035 24826 24095 23521 22143 20427 18208 16060
30 4.62 31 4.67 31 4.68 32 4.72 32 4.75 32 4.83 32 4.87 33 4.94 34 5.03
901 8740
26489 25672 25467 24778 24218 22864 21261 19163 17029
31 4.96 32 5.01 32 5.02 33 5.06 34 5.09 34 5.17 34 5.22 34 5.29 35 5.37
BHH 36B - Belt Drive Fan Data
Breezeway
Performance shown is for installation Type A: Free Inlet, Free Outlet. Power rating (BHP) does not include drive losses. The sound ratings shown are for loudness values
in fan sones at 5'0" (1.5m) in a hemispherical free fi eld per AMCA standard 301. Values shown are for installation Type A: Free inlet fan sone levels. Performance ratings
do not include the effects of appurtenances in the airstream. For further information on sound classifi cation, see page 40. For accessories, see pages 3 thru 7.
