PennBarry Fumex - FAN SELECTIONS; Model Identification & Construction Codes; Motor Specifications & Codes

www.PennBarry.com 17
FAN SELECTIONS
Model
FX = Fumex centrifugal roof exhaust upblast fan
Construction
Motor
Application
E = Exhaust / Relief
S = Supply / Intake
Application Flow (CFM)
<enter value>
Application Static Pressure (inwg)
<enter value>
Drive Type
B = Belt
D = Direct
T = Belt w/Tensioner
Fan RPM
<####>
Unit Size
8, 81, 10, 101, 11, 12, 121, 13, 131, 14,
141, 16, 161, 18, 181, 24, 241, 27, 30,
36
Wheel Width
0 = Standard
H = High pressure
Eciency
G = Green Plus (ECM)
P = Premium
S = Standard
Horsepower
0.020 = 1/50
0.033 = 1/30
0.050 = 1/20
0.040 = 1/25
0.083 = 1/12
0.091 = 1/11
0.143 = 1/7
0.167 = 1/6
0.200 = 1/5
0.250 = 1/4
0.333 = 1/3
0.500 = 1/2
0.750 = 3/4
01.00 = 1
01.50 = 1 1/2
02.00 = 2
03.00 = 3
05.00 = 5
07.50 = 7 1/2
10.00 = 10
15.00 = 15
20.00 = 20
25.00 = 25
X = Special
Motors and Drives
F = Factory mounted
L = Less motor less drive
M = Less motor with drive
Motor Enclosure
0 = None
1 = TE w/Overload
2 = TE w/o Overload
3 = ODP w/Overload
4 = ODP w/o Overload
5 = EXP C2D1
X = Special
Motor Tap
0 = None
K = 1650 RPM (Q1)
L = 500 RPM
M = 690 RPM
Q = 1750 RPM (Q2)
R = 1550 RPM
S = 1300 RPM
V = 1050 RPM
W = 860 RPM (W1,W2,W3)
Voltage/Phase/Cycle
1 = 380V/1PH/50HZ
2 = 400V/1PH/50HZ
3 = 415V/1PH/50HZ
4 = 460V/1PH/60HZ
B = 110V/1PH/50HZ*
C = 115V/1PH/60HZ
D=120V/1PH/60HZ*
F = 208V/1PH/60HZ
G = 208V/3PH/60HZ
H = 220V/1PH/50HZ*
J = 220V/3PH/50HZ*
K = 230V/1PH/60HZ
L = 230V/3PH/60HZ
M = 240V/1PH/50HZ*
N = 240V/3PH/50HZ*
P = 277V/1PH/60HZ*#
Q = 380V/3PH/50HZ*
R = 380V/3PH/60HZ*
S = 400V/3PH/50HZ*
T = 415V/3PH/50HZ*
U = 440V/3PH/50HZ*
V = 460V/3PH/60HZ
W = 480V/3PH/60HZ*
X = Special
Y = 575V/3PH/60HZ
* Non-standard offering subject to
longer lead times and price adjustment
# 277V applications require a
transformer
