Item No. QTY Part No. Description
1 ..............1 ...... 1000232 ..........Valve Assembly, w/o Flow
Controls
2 ..............1 ...............................Camshaft:
....... 1031950 ..........Standard, One-Piece
....... 1033024 ..........Standard, Segmented
....... 1033025 ..........Extra Salt, Segmented
....... 1033026 ..........Long Rinse, Segmented
....... 1032969 ..........Water Saver, Segmented
3 ..............1 ...... 3019873 ..........Lever, Locking Cam
4 ..............1 ...... 1031391 ..........Timer Locking Pin
5 ..............1 ...... 1000226 ..........Screen/Cap Assembly
w/O-Ring
6 ..............1 ...............................Drain Control Assembly
w/O-Rings:
....... 1000209 ..........No. 7 (1.2 gpm; 4.5 Lpm)
....... 1000210 ..........No. 8 (1.6 gpm; 6.1 Lpm)
....... 1000211 ..........No. 9 (2.0 gpm; 7.6 Lpm)
....... 1000212 ..........No. 10 (2.5 gpm; 9.5 Lpm)
....... 1000213 ..........No. 12 (3.5 gpm; 13.2 Lpm)
....... 1000214 ..........No. 13 (4.1 gpm; 15.5 Lpm)**
....... 1000215 ..........No. 14 (4.8 gpm; 18.2 Lpm)**
7 ..............2 ...... 1030502 ..........Ball, Flow control
8 ..............1 ...............................Brine Refill Control:
....... 1034261 ..........1 to 10 lbs Salt
....... 1034263 ..........3 to 19 lbs Salt
9 ..............1 ...............................Injector Assembly with
O-Rings:
....... 1032970 ..........“A” Injector - White
....... 1032971 ..........“B” Injector - Blue
....... 1032972 ..........“C” Injector - Red
10 ............1 ...... 1000269 ..........Injector Cap with O-Ring
11 ............1 ...... 3019870 ..........i-Lid Cover
12 ............1 ...... 1032416 ..........Air Check Kit
13 ............1 ...... 1010154 ..........O-Ring EPDM
14 ............1 ...... 1232370 ..........O-Ring EP
15 ............1 ...............................Locking Bar:
....... 1031402 ..........English Language
....... 1031403 ..........French Language
....... 1031404 ..........German Language
....... 1031405 ..........Italian Language
....... 1031406 ..........Japanese Language
....... 1031407 ..........Spanish Language
16 ............1 ...... 1006093 ..........Screw, No. 8 x 9/16 inch
17 ............1 ...... 1235341 ..........Spring, one pc 255
Kits
18 ..................... 1001404 ..........O-Ring Group: Tank Adapter,
1010117 (1), 1010407 (1),
1010410 (4)
19 ..................... 1040459 ..........O-Ring Group: Piping Boss
1010431 (1), 1010411 (2)
20 ..................... 1041010 ..........13/16 inch Rubber Insert
(Optional)
Valve Discs
* ....................... 1000250 ..........Standard
*Not Shown
**FLow control does not use Flow Control Ball (1030502).
Item No. QTY Part No. Description
255 VALVE & TANK ADAPTER MODULE
continued
AUTOTROL
®
255 Valve/400 Series Service Manual • 11
