Pentair BERKELEY LTH Series User Manual

12
BE30 (11-21-19)
MODEL NUMBER
Key
No.
Part Description
LTH - 1
1 HP
LTH - 1
1
⁄2
1-1.2 HP
LTH - 2
2 HP
LTH - 2
1
⁄2
2-1/2 HP
1 Motor, 115/230V, 1 Phase A100ELL A100FLL — —
1 Motor, 230V, 1 Phase — — A100GSLL AE100G5LL
1 Motor, 230/460V, 3 Phase AP100EL AP100FL AP100GL AP100G5L
2 Water Slinger 17351-0009 17351-0009 17351-0009 17351-0009
3 Seal Plate C3-155 C3-155 C3-117 C3-117
4 Gasket - Seal Plate C20-86 C20-86 C20-87 C20-87
4A O-Ring 25276 25276 34516 34516
5 Shaft Seal U109-6A U109-6A U109-6A U109-6A
6 Impeller C105-92PKB C105-92PCB C105-214PDA C105-214PA
6A Impeller Screw (1 Phase) — — C30-14SS C30-14SS
6A Impeller Screw (3 Phase) C30-14SS C30-14SS C30-14SS C30-14SS
7 Diffuser C101-276P C101-276P C101-182 C101-182
7B Screw 1/4-20 x1” Lg.(2) U30-696SS U30-696SS — —
7B Machine screw 8-32x7/8” Lg. (2) — — U30-53SS U30-53SS
8 Diffuser Ring C21-10 C21-10 C21-2 C21-2
9 Pump Body Assembly C176-49B C176-49B C76-50 C76-50
10 Base U4-5 U4-5 U4-5 U4-5
11 Pipe Plug 3/4” NPT - Sq. Hd. U78-60ZPS U78-60ZPS U78-60ZPS U78-60ZPS
12 Plug 1/4” NPT Hex. Hd. U78-941ZPV U78-941ZPV U78-941ZPV U78-941ZPV
13 Capscrew 3/8-16x3/4” Lg (6) U30-72ZP U30-72ZP — —
13 Capscrew 5/16-18x3/4” Lg.(8) — — U30-60ZP U30-60ZP
14 3/8-16x1” Capscrew (4) U30-74ZP U30-74ZP U30-74ZP U30-74ZP**
• Lockwasher 3/8” (4) U43-12ZP U43-12ZP — —
• Lockwasher - 3/8” (2) U43-12ZP U43-12ZP U43-12ZP U43-12ZP
• Capscrew 3/8-16x5/8” Lg (2) U30-71ZP U30-71ZP U30-71ZP U30-71ZP
• Not illustrated
**
Model LTH-2
1
⁄2 uses 4 U30-104ZP Socket Head Capscrews.
NOTE: Quantity is one unless otherwise noted noted in parenthesis ( ).
