11
P15008 (04-15-2023)
REPAIR PARTS
KEY
NO.
PART
DESCRIPTION
QTY.
USED
JHCT-61H
JBHCT-61S
JHC3T-61H
JBHC3T-61S
JHDT-62H
JBHDT-62S
JHD3T-62H
JBHD3T-62S
JHET-63H
JBHET-63S
JHE3T-63H
JBHE3T-63S
JHFT-51H
JBHFT-51S
JHF3T-51H
JBHF3T-51S
JHGT-52H
JBHGT-52S
JHG3T-52H
JBHG3T-52S
JBHHGT-53S
JHHG3T-53H
JBHHG3T-53S
1/2 HP 3/4 HP 1 HP
1-1/2 HP
2 HP 2-1/2 HP
1 Motor - 115/230v, 1ph 1 A1 0 0 C L-T A100DL-T A100EL-T A100FL-T AE100GL-T AE 1 0 0 G 5 L-T
1 Motor - 230/460v, 3ph 1 A P 1 0 0 C L-T AP100DL-T AP100EL-T AP100FL-T AP100GL-T A P 10 0 G 5 L-T
2 Water Slinger 1 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009
3 Seal Plate 1 C3-178 C3-178 C3-178 C3-178 C3-181 C3-181
4 Seal Plate Gasket 1 C20-121N C20-121N C20-121N C20-121N C20-122N C20-122N
5 Shaft Seal 1 U109-6B U109-6B U109-6B U109-6B U109-6B U109-6B
6 Impeller - Noryl, 1ph 1 C105-92PNX C105-92PM X C105-92PLX C105-92PBX C105-214PCA -
6 Impeller - Bronze, 1ph 1 C5-256BA C5-256BAA C5-254BA C5-254BC C5-297BB C5-297B
6 Impeller - Noryl, 3ph 1 C105-92PNXA C105-92PMXA C105-92PLXA C105-92PBXA C105-214PCA C105-214PA
6 Impeller - Bronze, 3ph 1 C5-256BA C5-256BAA C5-254BA C5-254BC C5-297BB C5-297B
6A Impeller Screw 1 C30-14SS** C30-14SS** C30-14SS** C30-14SS** C30-14SS C30-14SS
7
Volute Assembly with
Wear Ring
1 C101-284A C101-284A C101-284A C101-284A C101-264 C101-264B
7A Wear Ring 1 C23-27 C23-27 C23-27 C23-27 C23-19 C23-19
8
Pipe Plug, 1/4” NPT
Sq. Hd.
1 - - - - - -
8
Pipe Plug, 1/4” NPT
Hex Hd.
( ) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV U78-941ZPV U78-941ZPV (3) U78-941ZPV (3)
9 Base 1 J104-9A J104-9A J104-9A J104-9A J104-9A J104-9A
9A Motor Pad 1 C35-5S C35-5S C35-5S C35-5S C35-5S C35-5S
10
Socket Head
Capscrew, 3/8” - 16 x
1-1/4” Lg.
4 U30-104ZP U30-104ZP U30-104ZP U30-104ZP U30-104ZP U30-104ZP
11 Stud, 3/8 - 16 x 1-13/16” 4 - - - - - -
12 Hex Nut, 3/8 - 16 4 - - - - - -
Seal Kit
PP1700 PP1700 PP1700 PP1700 PP1700 PP1700
Includes 2, 4, 5
* Not Pictured
**3ph Only
STA-RITE MODELS (TEFC MOTORS)
