P15008 (04-15-2023)
REPAIR PARTS
KEY
NO.
PART
DESCRIPTION
QTY.
USED
JMCT-56
JBMCT-56S
JMC3T-56
JBMC3T-56S
JMDT-57
JMD3T-57
JBMD3T-57S
JMET-58
JBMET-58S
JME3T-58
JBME3T-58S
JMFT-40
JBMFT-40S
JMF3T-40
JBMF3T-40S
JMGT-41
JBMGT-41S
JMG3T-41
JBMG3T-41S
JBMMGT-59S
JBMMG3T-59S
1/2 HP 3/4 HP 1 HP 1-1/2 HP 2 HP 2-1/2 HP
1 Motor - 115/230v, 1ph 1 A10 0 CL-T
A100DL-T A100EL-T A100FL-T AE100GL-T A E1 0 0 G 5 L-T
1 Motor - 230/460v, 3ph 1 A P 10 0 C L-T
AP100DL-T AP100EL-T AP100FL-T AP100GL-T A P1 0 0 G5 L-T
2 Water Slinger 1 17351-0009
17351-0009 17351-0009 17351-0009 17351-0009 17351-0009
3 Seal Plate 1 N3-8
N3-8 N3-8 C3-52 C3-52 C3-52
4 Seal Plate Gasket 1 N20-26N
N20-26N N20-26N C20-21N C20-21N C20-21N
5 Shaft Seal 1 U109-6B
U109-6B U109-6B U109-6B U109-6B U109-6B
6 Impeller - Noryl, 1ph 1 J105-42PHA
J105-42PJA J105-42P C105-114PNF C105-114PNGA -
6 Impeller - Bronze, 1ph 1 J105-42MA
- J105-42NA C105-79BA C105-73BA C105-80DA
6 Impeller - Noryl, 3ph 1 J105-42PHA
J105-42PJA J105-42PPA C105-114PNFA C105-114PNGA -
6 Impeller - Bronze, 3ph 1 J105-42MA
J105-42LA J105-42NA C105-79BA C105-73BA C105-80DA
6A Impeller Screw 1 C30-6SS**
C30-6SS** C30-6SS** C30-14SS** C30-14SS** C30-14SS**
7
Volute Assembly with
Wear Ring
1 C101-122E
C101-122E C101-122 C101-123 C101-123 C101-123B
7A Wear Ring 1 N23-7
N23-7 N23-7 C23-19 C23-19 C23-19
8
Pipe Plug, 1/4” NPT
Sq. Hd.
1 -
- - U78-57DT U78-57DT U78-57DT
8
Pipe Plug, 1/4” NPT
Hex Hd.
( ) U78-941ZPV (4)
U78-941ZPV (4) U78-941ZPV (4) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3)
9 Base 1 J104-9A
J104-9A J104-9A J104-9A J104-9A J104-9A
9A Motor Pad 1 C35-5
C35-5 C35-5 C35-5S C35-5S C35-5S
10
Socket Head
Capscrew, 3/8” - 16 x
1-1/4” Lg.
4 U30-104ZP
U30-104ZP U30-104ZP - - -
11 Stud, 3/8 - 16 x 1-13/16” 4 -
- - U30-35SS U30-35SS U30-35SS
12 Hex Nut, 3/8 - 16 4 -
- - U36-38ZP U36-38ZP U36-38ZP
Seal Kit
PP1700
PP1700 PP1700 PP1700 PP1700 PP1700
Includes 2, 4, 5
* Not Pictured
**3ph Only
