14
P15008 (04-15-2023)
REPAIR PARTS
KEY
NO.
PART
DESCRIPTION
QTY.
USED
S39516
S39529
S39517
S39530
S39518
S39531
S39519
S39532
S39520
S39533
S39521
S39534
S39522
S39535
S39523
S39536
S39524
S39537
S39525
S39538
S39526
S39539
S39527
S39540
1/2 HP 3/4 HP 1 HP 1-1/2 HP 2 HP 2-1/2 HP
1
Motor - 115/230v, 1ph,
ODP
1 J218-1651 J218-1652 J218-1653 J218-1655 J218-1656 J218-1657
1
Motor - 230/460v, 3ph
ODP
1 AP100CL AP100DL AP100EL AP100FL AP100GL AP100G5L
2 Water Slinger 1 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009
3 Seal Plate 1 C3-178 C3-178 C3-178 C3-178 C3-181 C3-181
4 Seal Plate Gasket 1 C20-121N C20-121N C20-121N C20-121N C20-122N C20-122N
5 Shaft Seal 1 U109-6B U109-6B U109-6B U109-6B U109-6B U109-6B
6 Impeller - Noryl, 1ph 1 C105-92PN C105-92PM C105-92PL C105-92PB C105-214PCAB C105-214PAB
Impeller - Bronze, 1ph 1 C5-256BA C5-256BAA C5-254BA C5-254BC C5-297BB C5-297B
6 Impeller - Noryl, 3ph 1 C105-92PNA C105-92PMA C105-92PLA C105-92PBA C105-214PCAB C105-214PAB
Impeller - Bronze, 3ph 1 C5-256BA C5-256BAA C5-254BA C5-254BC C5-297BB C5-297B
6A Impeller Screw 1 C30-14SS** C30-14SS** C30-14SS** C30-14SS** C30-14SS C30-14SS
7
Volute Assembly with
Wear Ring
1 C101-284E C101-284E C101-284E C101-284E C101-264E C101-264EB
7A Wear Ring 1 C23-27 C23-27 C23-27 C23-27 C23-19 C23-19
8
Pipe Plug, 1/4” NPT
Sq. Hd.
1 - - - - - -
9
Pipe Plug, 1/4” NPT
Hex Hd.
( ) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3)
10 Base 1 J104-9F J104-9F J104-9F J104-9F J104-9F J104-9F
10A Motor Pad 1 C35-5S C35-5S C35-5S C35-5S C35-5S C35-5S
11 Stud, 3/8 - 16 x 1-13/16 4 - - - - - -
12 Hex Nut, 3/8 - 16 4 - - - - - -
12*
Hex Capscrew, 3/8" -
16 x 1-1/2" Lg. (Bottom)
( ) - - - - - -
12*
Hex Capscrew, 3/8" -
16 x 1-1/4" Lg. (Top)
( ) U30-75ZP (4) U30-75ZP (4) U30-75ZP (4) U30-75ZP (4) U30-75ZP (2) U30-75ZP (2)
12*
Hex Capscrew, 3/8" -
16 x 1" Lg. (Bottom)
( ) - - - - U30-74ZP (2) U30-74ZP (2)
Seal Kit
PP1700 PP1700 PP1700 PP1700 PP1700 PP1700
Includes 2, 4, 5
* Not Pictured
**3ph Only
BERKELEY MODELS (ODP MOTORS)
