REPAIR PARTS
KEY
NO.
PART
DESCRIPTION
QTY.
USED
S39490
S39503
S39491
S39504
S39492
S39505
S39493
S39506
S39494
S39507
S39495
S39508
S39496
S39509
S39497
S39510
S39498
S39511
S39499
S39512
S39500
S39513
S39514
1/2 HP 3/4 HP 1 HP 1-1/2 HP 2 HP 2-1/2 HP
1
Motor - 115/230v, 1ph,
ODP
1 J218-1651 J218-1652 J218-1653 J218-1655 J218-1656 J218-1657
1
Motor - 230/460v, 3ph
ODP
1 AP100CL AP100DL AP100EL AP100FL AP100GL AP100G5L
2 Water Slinger 1 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009
3 Seal Plate 1 N3-8 N3-8 N3-8 C3-52 C3-52 C3-52
4 Seal Plate Gasket 1 N20-26N N20-26N N20-26N C20-21N C20-21N C20-21N
5 Shaft Seal 1 U109-6B U109-6B U109-6B U109-6B U109-6B U109-6B
6 Impeller - Noryl, 1ph 1 J105-42PHA J105-42PJA J105-42P C105-114PNF C105-114PNGA -
Impeller - Bronze, 1ph 1 J105-42MA J105-42LA J105-42NA C105-79BA C105-73BA C105-80DA
6 Impeller - Noryl, 3ph 1 J105-42PHA J105-42PJA J105-42PPA C105-114PNFA C105-114PNGA -
Impeller - Bronze, 3ph 1 J105-42MA J105-42LA J105-42NA C105-79BA C105-73BA C105-80DA
6A Impeller Screw 1 C30-6SS** C30-6SS** C30-6SS** C30-14SS** C30-14SS C30-14SS
7
Volute Assembly with
Wear Ring
1 C101-122E C101-122E C101-122 C101-123 C101-123 C101-123B
7A Wear Ring 1 N23-7 N23-7 N23-7 C23-19 C23-19 C23-19
8
Pipe Plug, 1/4” NPT
Sq. Hd.
1 - - - U78-57DT U78-57DT U78-57DT
9
Pipe Plug, 1/4” NPT
Hex Hd.
( ) U78-941ZPV (4) U78-941ZPV (4) U78-941ZPV (4) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV
10 Base 1 J104-9F J104-9F J104-9F J104-9F J104-9F J104-9F
10A Motor Pad 1 C35-5S C35-5S C35-5S C35-5S C35-5S C35-5S
11 Stud, 3/8 - 16 x 1-13/16” 4 - - - U30-35SS U30-35SS U30-35SS
12 Hex Nut, 3/8 - 16 4 - - - U36-38ZP U36-38ZP U36-38ZP
12*
Hex Capscrew, 3/8" -
16 x 1-1/2" Lg. (Bottom)
( ) U30-76ZP (2) U30-76ZP (2) U30-76ZP (2) - - -
12*
Hex Capscrew, 3/8" -
16 x 1-1/4" Lg. (Top)
( ) U30-75ZP (2) U30-75ZP (2) U30-75ZP (2) - - -
12*
Hex Capscrew, 3/8" -
16 x 1" Lg. (Bottom)
( ) - - - - - -
Seal Kit
PP1700 PP1700 PP1700 PP1700 PP1700 PP1700
Includes 2, 4, 5
* Not Pictured
**3ph Only
