INTELLIFLO
®
Variable Speed Pump Demo Kiosk Operation and Set Up Instructions
INTELLIFLO
®
Variable Speed Pump Demo Kiosk Operation and Set Up Instructions
Right click here
to exit
Informational IntelliFlo Pump Video: Select ‘Click Here to
Learn More About IntelliFlo’ on the Comparative Cost Calcu-
lator screen to play a video about IntelliFlo pump technology.
Meter Screen: Shows actual reading from IntelliFlo pump
from the demo unit. These are the same readings from the
Comparative Cost Calculator screen.
3. To exit the Comparative Cost Calculator screen,
right click on the upper left corner of the screen,
in the space just to the left of the “Standard
Pump” heading.
4. The ‘Meter Screen’ will appear, showing the
actual reading from the IntelliFlo
®
pump running
on the demo unit. These are the same readings
shown on the IntelliFlo pump portion (right side)
of the Comparative Cost Calculator screen.
5. To exit the program completely, move the cursor
to the bottom center of the Meter Screen. A row
of tabs will appear. Right click within the tabs
area.
6. Next a “Program Options” and also and an“Exit”
tab appears. Left click on the Exit tab, to close
out of the Pentair program
To Exit: Move cursor
here and right click

Pentair IntelliFlo Specifications

General

Pump Type	Variable Speed
Horsepower	3.0 HP
Voltage	230V
Energy Efficiency	Energy Star Certified
Warranty	3 years
Maximum Flow Rate	160 GPM
Wet End Material	Composite
Control Interface	Digital
Speed Settings	8 Programmable Speeds
