Shift shaft JP42770
Microswitch JP46351
①
Schaltwelle
②
Mikroschalter
③
Kondensator Capacitor
JP46015
④
Anschlusseinheit Top cover
JP46389
JP46390
U5 K, 10m
U5 KS, 4m
U5 KS, 10m
JP46391
Float JP42771
Motor JP46388
Seals JP46385
Impeller JP46363
Elbow JP46355
Rubber ap JP46366
Volute casing JP46364
Seal set JP46354
Cover JP46387
Screw set JP42773
⑤
Schwimmer
⑥
Motor
⑦
Dichtungen
⑧
Laufrad
⑨
Winkel
⑩
Gummiklappe
⑪
Spiralgehäuse
⑫
Dichtungssatz
⑬
Deckel
⑭
Schraubensatz
⑮
Siebfuß Strainer base
JP46365
U5K · U5KS
Spare parts
