Pentax G6 - Page 7

7
the number of locked satellites. When the receiver doesn’t lock satellites, the
satellite led does not shine.
Figure 1- 2 Satellite led
Network led (green)
This light is on when GSM/GPRS module is selected as RTK datalink. It starts to
blink when there is data transfer ongoing (In both radio, Bluetooth and network
data link mode, it will blink when there is data transfer ongoing).
Figure 1- 3 Network led
power led (green and red)
When you power on the G6, the power led will be on. According to the remaining
power of the battery, it includes two kinds of status:
1. Green: power supply in good condition.
2. Red: power is less than 10%(when the total power of two batteries is less
than 10%,the power led is red),and you will hear three beeps every 60s.
Figure 1-4 Power led
Note: Usually when the light is red you have still half an hour of power reserve.
External power and internal battery share same power light. When external power is
