Pentax G6 - Page 9

9
Figure 1-6 G6 bottom
Figure 1- 11 5-PIN interface Figure 1- 12 7-PIN interface
Number
Name
Function
1
Beeper
Broadcast voice message
2
5 pin interface
Connect to external radio and external
battery
3
7 pin interface
USB port, also can connect to the
controller via the multi-function cable
4
Radio antenna interface
Connect to radio antenna
