1.
BEFORE USING
THE INSTRUMENT
1.1 Names of par
ts
A shift fixed screw is attached to Base plate of a shift base type model.
9
Collimator
Po
wer focus key
Eyepiece ring
Eyepiece
Laser indicator
Circulator vial
CF card slot
Display panel
Key board
RS-232C connector
Leveling scr
ew
F
ocus ring
AF buton
Instrument height mark
Battery latch
Battery pack
T
elescope tangent screw
T
elescope clamp screw
Clamp screw
T
angent screw
SD card slot
USB connector
T
op handle
Detaching knob
Base plate
Objective lens
10
12
Table of Contents
