BTC12N-*
Product Description
2020-05
9
The additional VisuNet Control Center (VisuNet CC) is a software tool for the centralized man-
agement of Pepperl+Fuchs VisuNet Remote Monitors (RMs) and Box Thin Clients (BTCs). The
software can be installed on any Windows®-based PC, such as a service Notebook or a virtual-
ized Engineering Workstation. It allows remote setup, management, and maintenance of all
RMs and BTCs that are connected to the same network infrastructure.
For more information about using RM Shell 5, see the VisuNet RM Shell manual.
ACP ThinManager Ready
As an alternative to the VisuNet RM Shell 5, the BTC12 can also be ordered as ACP ThinMan-
ager "Ready" option. The device is qualified, tested and listed with the following parameters:
Figure 2.4
For further information please refer to the according ACP ThinManager documentation.
https://kb.thinmanager.com/index.php/Supported_Hardware#Pepperl.2BFuchs
2.4 Technical Data
Hardware
Supply
Interface
Note
Please visit www.pepperl-fuchs.com regularly to check for the latest version of RM Shell.
Note
The standard version of the BTC12 is BTC12N-GP-TS2-DP-N0.
GP-versions are for ordinary locations. D2-versions are for hazardous locations.
GN-versions are not UL listed.
Processor Intel® Apollo Lake N4200 series
RAM 4 GB DDR3L
Mass storage 32 GB eMMC MLC
option PC2: additional 128 GB SSD
Power supply Input voltage: 16 ... 28 V DC
Input current: max. 2 A - 1 A
Input via 2.5 mm power socket (with double insulation
from the power supply)
Interface type front: 2 x USB 2.0, power button, audio line out
Back side: 2 x 1000Base-T Ethernet, 2 x DisplayPort™
1.2 (supports Ultra HD with 4K at 60 Hz), 1 x DC (DC
jack 5.5 x 2.5 mm with lock mechanism), 2 x USB 3.1
(Super Speed) , 1 x RS-232/RS-485 with DB-9 connec-
tor
