Door Interrupt System with FYQLA1-140R-3 Logic Amplier
Ambient conditions
Operating temperature -25 °C to +70 °C noncondensing
Storage temperature -25 °C to +70 °C noncondensing
Terminal block - power and relays
Conductor cross section capacity 0.2 mm² to 2.5 mm² (22 to 14 AWG) Cu
Tightening torque 0.5 Nm (4.5 lb-in)
Strip length 7 mm
Connection method Terminal block - screw connection
Terminal block - sensor inputs
Conductor cross section capacity 0.5 mm² to 2.5 mm² (22 to 14 AWG) Cu
Tightening torque 0.5 to 0.6 Nm (4.5 to 5.3 lb-in)
Strip length 6 mm
Connection method Terminal block - screw connection
General data
Dimensions - FYQLA1-140R-3 203.0 mm H x 135.0 mm W x 58.0 mm D
Mechanical service life (approx.) > 1,000,000 operations
Indicators
Sensor status
Relay status
Fault status
LED red, one per channel / two per input
LED green (2), red (2)
LED red, ashing
(See indicator status table, pg 11, for indication
denitions)
Product specications (cont.)
