K-System – Signal Conditioners
Mounting and Installation
Figure 3.5 Horizontal mounting of KF devices with 20 mm housing width (single device mounting)
Figure 3.6 Horizontal mounting of KF devices with 40 mm housing width (single device mounting)
20 ≥10 20 ≥10
40 ≥15 40 ≥15
