K-System – Signal Conditioners
Dismounting, Maintenance, and Repair
2023-03
39
6.1 Dismounting the Signal Conditioner
Dismounting the Signal Conditioner
Use for dismounting of the device a slotted screwdriver
1. Insert the screwdriver (4) into the groove of the red mounting slider (3).
2. Turn the screwdriver (4) in the groove until the red mounting slider (3) springs back.
3. Repeat these steps on the other side of the device.
4. Remove the isolator (2) from the DIN mounting rail (1).
Figure 6.1 Dismounting of the device from the DIN mounting rail
1 35 mm DIN mounting rail
2 Signal conditioner
3 Mounting slider
4 Slotted screwdriver
